Overview
Moreover, this 10-slot rack supports reliable installation of monitoring modules in critical rotating equipment environments.
Therefore, maintenance teams gain consistent system organization while simplifying future expansion or module replacement tasks.Designed for long-term industrial operation, the rack delivers proven durability across power generation, oil, and process industries.
In addition, its standardized layout ensures compatibility with legacy 3300 series monitors and power supply assemblies.
Specification
| Parameter | Description |
|---|---|
| Product Model | 3300/05-24-00-00 |
| Manufacturer | Bently Nevada |
| Product Type | Machinery Protection System Rack |
| Series Compatibility | Bently Nevada 3300 Monitoring System |
| Slot Capacity | 10 module slots |
| Supported Modules | 3300 series monitors, interfaces, and accessories |
| Power Supply Support | Single or dual 3300 series power supplies |
| Backplane Function | Integrated power distribution and signal interconnection |
| Mounting Method | Panel-mounted or cabinet-mounted installation |
| Rack Orientation | Vertical mounting within control cabinets |
| Construction Material | Industrial-grade metal chassis |
| Mechanical Design | Rigid frame for vibration-resistant operation |
| Electrical Interface | Passive backplane, no active electronic components |
| Service Access | Front-accessible module insertion and removal |
| Cooling Method | Natural convection, no forced airflow required |
| Environmental Usage | Continuous-duty industrial environments |
| Typical Operating Context | Turbines, compressors, pumps, motors |
| System Role | Centralized housing and organization for monitoring hardware |
| Compliance Purpose | Supports reliable long-term machinery protection architectures |
FAQ
The rack physically houses and interconnects 3300 series monitoring modules and power supplies securely.Q2: How many modules can this rack support?
This rack supports up to ten monitoring or interface modules simultaneously.
Q3: Is this rack compatible with all 3300 series monitors?
Yes, it supports standard Bently Nevada 3300 series monitors and associated power supplies.
Q4: Can the rack be used for system upgrades?
Moreover, it works well for maintaining or refurbishing existing 3300 monitoring systems without redesign.
Q5: Does the rack contain active electronic components?
No, the rack uses a passive design focused on mechanical support and signal backplane connectivity.
