Overview
Specification
| Parameter | Specification |
|---|---|
| Model Number | 14386‑03 |
| Manufacturer | Bently Nevada |
| Series | 3500 Proximitor I/O Module |
| Function | Proximity probe signal processing and machinery protection |
| Input Channels | 4 Proximitor sensor channels |
| Output Channels | 4 analog outputs, 4 relay outputs |
| Signal Type | AC or DC proximity probe signals |
| Frequency Response | 0.1 Hz to 20 kHz |
| Accuracy | ±0.2% full scale |
| Update Rate | 50–100 ms typical |
| Operating Temperature | -40°C to +85°C |
| Power Supply | 24 VDC nominal |
| Dimensions | 241 mm × 48 mm × 242 mm |
| Weight | ~0.85 kg |
| Mounting | 3500 series system rack |
| Compliance | CE and industrial standards approved |
FAQ
Q1: Is the 14386‑03 an original Bently Nevada module?
A1: Yes, the 14386‑03 is fully original and factory-certified by Bently Nevada.
Q2: How many Proximitor channels does it support?
A2: The module supports four Proximitor sensor channels.
Q3: Can it integrate with standard 3500 series racks?
A3: Yes, it installs seamlessly into 3500 series system racks.
Q4: What is the operating temperature range?
A4: It operates reliably between -40°C and +85°C.
Q5: Does it provide alarm outputs?
A5: Yes, it includes four relay outputs configurable for alarms.
Q6: What is the typical signal update rate?
A6: The module updates signals every 50–100 milliseconds.
