Overview
Specification
| Specification | Details |
|---|---|
| Model Number | 141378-01 |
| Manufacturer | Bently Nevada |
| Category | FieldMonitor 24V DC Power Supply |
| Input Voltage | 120–240 VAC, 50/60 Hz |
| Output Voltage | 24 VDC nominal |
| Output Current | 2.5 A continuous |
| Power Rating | 60 W typical |
| Efficiency | ≥ 85% typical |
| Operating Temperature | 0–60°C |
| Storage Temperature | -40–85°C |
| Humidity | 5–95% RH non-condensing |
| Protection Features | Overcurrent, short-circuit, thermal shutdown |
| Mounting | Rack mount or panel mount compatible |
| Weight | 1.1 kg |
| Dimensions (L×W×H) | 160 mm × 120 mm × 45 mm |
| Compliance / Certification | CE, UL listed |
| Typical Applications | FieldMonitor systems, vibration monitoring, industrial machinery protection |
FAQ
Q1: Is the 141378-01 power supply compatible with all FieldMonitor modules?
A1: Yes, it provides stable 24 VDC suitable for all standard FieldMonitor modules.
Q2: What protection features does this power supply include?
A2: It includes overcurrent, short-circuit, and thermal shutdown protection for safe operation.
Q3: Can this power supply operate in high-temperature environments?
A3: Yes, it operates reliably in 0–60°C, and can be stored at -40–85°C.
Q4: What is the maximum output current?
A4: The 141378-01 delivers up to 2.5 A continuous output current.
Q5: How is it mounted?
A5: It supports both rack and panel mounting for flexible integration into industrial systems.
Q6: Is the unit covered by warranty?
A6: Yes, it is fully factory-new, stocked, and eligible for support or return within 30 days in case of issues.
