Overview
Specification
| Parameter | Specification |
|---|---|
| Model Number | 1701/15 |
| Part Number | 141379-01 |
| Module Type | Proximitor Input Monitor |
| Measurement Type | Radial displacement / vibration |
| Input Signal | Compatible with 1700 Series Proximitor sensors |
| Output Signal | 4–20 mA analog or compatible with monitoring system inputs |
| Frequency Response | Up to 3000 Hz depending on configuration |
| Sensitivity | High, suitable for precision machinery monitoring |
| Power Requirements | 24 VDC nominal (typical rack-supplied) |
| Operating Temperature | 0°C to +65°C |
| Storage Temperature | –40°C to +85°C |
| Mounting | Rack-mounted, compatible with 1700 Series slots |
| Indicators | Status LEDs for power, signal, and health |
| Application Environment | Industrial rotating equipment, turbines, compressors, and pumps |
FAQ
A1: It precisely monitors radial vibration to detect early signs of mechanical faults.
Q2: Can it integrate with existing Bently Nevada systems?
A2: Yes, it is fully compatible with the 1700 Series Proximitor monitoring racks.
Q3: What environments can it operate in?
A3: It reliably operates in industrial settings with electrical noise and mechanical vibration.
Q4: What is the operating temperature range?
A4: The monitor functions between 0°C and +65°C under normal conditions.
Q5: Does it provide alerts for machinery faults?
A5: Yes, it enables early warnings by detecting abnormal vibration patterns.
