Overview
Moreover, this module integrates internal terminations, which simplify wiring while improving installation consistency across protection cabinets.
In addition, engineers rely on this module to maintain stable pressure monitoring for critical rotating machinery applications.
Specification
| Category | Specification |
|---|---|
| Product Model | 140471-02 |
| Manufacturer | Bently Nevada |
| Product Series | 3500 Machinery Protection System |
| Module Type | Dynamic Pressure I/O Module |
| Termination Style | Internal terminations |
| Supported Monitor | 3500/64M Dynamic Pressure Monitor |
| Signal Type | Dynamic pressure transducer signals |
| Number of Input Channels | 4 channels |
| Channel Configuration | Independent per channel |
| Input Signal Range | Sensor-dependent, configured through 3500 system |
| Signal Conditioning | Performed by associated 3500 monitor module |
| Channel Isolation | Channel-to-channel electrical isolation |
| Backplane Interface | 3500 rack proprietary data bus |
| Power Supply Source | Supplied directly from 3500 rack backplane |
| External Power Required | None |
| Energy Storage Components | No internal batteries or large capacitors |
| Field Wiring Connection | Internal screw terminal blocks |
| Wiring Method | Direct sensor wiring to internal terminations |
| Mounting Type | Slides into designated 3500 rack slot |
| Rack Compatibility | Standard 3500 19-inch rack |
| Operating Temperature | Follows 3500 system environmental specifications |
| Storage Temperature | Follows 3500 system storage specifications |
| Relative Humidity | Non-condensing, per 3500 system limits |
| Vibration Resistance | Designed for continuous high-vibration environments |
| EMC Compliance | Meets industrial EMC requirements within 3500 system |
| Physical Height | Approx. 241 mm |
| Physical Width | Approx. 24.4 mm |
| Physical Depth | Approx. 241 mm |
| Net Weight | Approx. 0.34 kg |
| Typical Service Life | Designed for long-term continuous operation |
| Firmware | Not applicable, no onboard processing |
| Redundancy Support | Depends on system-level rack configuration |
| Certification | Conforms to Bently Nevada 3500 system standards |
FAQ
A1: Yes, the 140471-02 is brand new, factory original, and supplied in genuine Bently Nevada packaging.
Q2: Do you keep the 140471-02 module in stock?
A2: Yes, we maintain ready stock for the 140471-02, therefore supporting fast fulfillment for urgent machinery protection projects.
Q3: How long does shipping usually take after placing an order?
A3: Shipping typically takes three days to two weeks, depending on order quantity, destination, and logistics arrangements.
Q4: Which logistics providers do you normally use for delivery?
A4: We commonly use DHL and similar international carriers, therefore ensuring reliable tracking and timely global delivery.
Q5: Does the 140471-02 support internal terminations for dynamic pressure sensors?
A5: Yes, the 140471-02 includes internal terminations, which simplifies field wiring and reduces installation complexity.
Q6: What is your return policy if quality issues occur?
A6: We support returns within thirty days if quality problems arise, therefore protecting customers throughout commissioning and startup.
