Overview
Honeywell designs the 51403776-100 processor spacer board to optimize module spacing within TDC 3000 control system racks.
It improves airflow distribution and ensures stable electrical connections between processor modules and adjacent system boards.
Moreover, this spacer board enhances installation flexibility while maintaining structural integrity across complex automation cabinet configurations.
Core Features
The 51403776-100 provides precise mechanical spacing for processor boards and reduces thermal accumulation during continuous system operation.
Additionally, it supports consistent connector alignment and improves signal transmission stability across interconnected TDC 3000 modules.
Furthermore, Honeywell selects durable materials to ensure long-term performance under demanding industrial environmental conditions.
Specification
| Parameter | Description |
|---|---|
| Manufacturer | Honeywell |
| Model | 51403776-100 |
| Product Type | Processor Spacer Board |
| System Series | TDC 3000 Distributed Control System |
| Function | Mechanical spacing and electrical connection support for processor modules |
| Board Type | Passive spacer and interconnection board |
| Interface Type | Edge connectors compatible with TDC 3000 backplane system |
| Number of Connectors | Multiple high-density connectors for module alignment and signal continuity |
| Connector Material | Gold-plated contacts for reliable conductivity and corrosion resistance |
| Signal Support | Pass-through signal routing for processor module communication stability |
| Power Handling | Supports low-level signal and auxiliary power distribution through connectors |
| Energy Storage | No active energy storage components integrated on board design |
| PCB Structure | Multi-layer printed circuit board for signal integrity and durability |
| Component Count | Minimal active components with focus on connectors and routing traces |
| Mounting Type | Rack-mounted within TDC 3000 cabinet system architecture |
| Alignment Function | Ensures precise spacing between processor and adjacent system modules |
| Cooling Contribution | Improves airflow channeling between densely installed control boards |
| Material | صنعتی grade FR-4 substrate with reinforced structural design |
| Dimensions | Standard TDC 3000 board dimensions for seamless rack integration compatibility |
| Thickness | Optimized thickness to maintain structural rigidity and connector stability |
| Weight | Lightweight design suitable for high-density system installations |
| Operating Temperature | 0°C to 60°C for industrial control room operational environments |
| Storage Temperature | -20°C to 70°C for safe storage and transportation conditions |
| Humidity Range | 5% to 95% non-condensing industrial environment compatibility |
| Compatibility | Fully compatible with Honeywell TDC 3000 processor and control modules |
| Application | Used in industrial automation systems including oil gas chemical and power plants |
FAQ
Q1: What condition is the 51403776-100 spacer board supplied in?
We supply the 51403776-100 in brand new original factory sealed condition for industrial automation applications.
Q2: Do you keep this model in stock and how quickly can you ship?
We maintain stock and ship within three days to two weeks depending on order size and demand.
Q3: Which logistics services do you typically use for delivery?
We commonly use DHL and similar express carriers to ensure fast and reliable global delivery services.
Q4: Does this spacer board include active electronic components or processing capability?
The 51403776-100 focuses on spacing and connection support and does not include active processing components.
Q5: Do you support returns if quality issues occur after delivery?
We support a thirty-day return policy if verified quality issues appear after delivery and inspection.
