Overview
Specification
| Specification | Details |
|---|---|
| Input Voltage | 120/240 V AC ±10%, 50/60 Hz |
| Input Current | 2.0 A at 120 V AC, 1.0 A at 240 V AC |
| Input Protection | Fuse-protected, surge suppression, inrush current limiting |
| Output Voltage | +5 V DC at 5 A, +24 V DC at 2 A |
| Output Ripple & Noise | <50 mV peak-to-peak, low noise suitable for control modules |
| Output Protection | Overvoltage, overcurrent, short-circuit protection |
| Power Rating | 50 W maximum |
| Efficiency | >85% typical, depending on load |
| Load Regulation | ±2% for +5 V, ±3% for +24 V |
| Line Regulation | ±1% typical |
| Temperature Coefficient | ±0.03% / °C |
| Operating Temperature Range | 0°C to 60°C |
| Storage Temperature Range | -20°C to 70°C |
| Relative Humidity | 5% – 95% non-condensing |
| Cooling | Convection cooled, no fan required |
| MTBF (Mean Time Between Failures) | 100,000 hours @ 25°C |
| Mounting | Honeywell FSC Series Rack, modular design |
| Dimensions (H x W x D) | 100 x 50 x 150 mm |
| Weight | 1.2 kg |
| Safety & Certifications | UL Listed, CE Marked, CSA certified |
| Diagnostics | LED status indicators for power, fault, and load status |
| Compliance Standards | IEC 61010-1, EN 60204-1 industrial electrical safety standards |
| Integration Features | Compatible with all FSC I/O and CPU modules, hot-swap capability |
FAQ
A1: What voltage outputs does the 900P02-0001 provide?
Q1: It provides +5 V DC at 5 A and +24 V DC at 2 A, suitable for FSC modules.
A2: Can this power supply module operate in harsh industrial environments?
Q2: Yes, it functions reliably between 0°C and 60°C and meets UL, CE, and CSA standards.
A3: Is the module compatible with existing FSC racks?
Q3: Absolutely, it installs directly into FSC series racks for seamless integration.
A4: How does the module enhance system reliability?
Q4: Integrated diagnostics, LED indicators, and fault detection reduce downtime risks.
A5: Can I replace the module without shutting down the system?
Q5: Yes, its modular design allows hot-swap replacement while maintaining system power.
