Overview
Specification
| Parameter | Specification / Details |
|---|---|
| Model Number | 900G02-0202 |
| Series | FSC (Field System Controller) |
| Module Type | Digital Input Module |
| Input Channels | 16 discrete inputs per module |
| Input Voltage | 24 VDC nominal |
| Input Type | Dry contact, TTL compatible |
| Input Current | 3 mA typical per channel |
| Isolation | Channel-to-channel: 500 VDC; Module-to-backplane: 2500 VDC |
| Response Time | <5 ms per channel |
| Communication Interface | FSC backplane connection |
| Operating Temperature | 0°C to 60°C (32°F to 140°F) |
| Storage Temperature | -40°C to 85°C (-40°F to 185°F) |
| Humidity | 5% to 95% non-condensing |
| Vibration Resistance | 5–500 Hz, 0.5 g RMS |
| Shock Resistance | 15 g, 11 ms half-sine pulse |
| Mounting | 19-inch rack compatible; optional DIN rail mounting |
| Dimensions | 160 mm x 120 mm x 40 mm (approx.) |
| Weight | 0.7 kg (approx.) |
| Compliance / Certification | CE, UL, CSA, RoHS |
| Maintenance | Hot-swappable; supports preventive maintenance and diagnostics |
FAQ
Q1: How many discrete inputs does this module support?
A1: The 900G02-0202 supports 16 discrete input channels per module for flexible system integration.
Q2: Can this module be installed without shutting down the system?
A2: Yes, the module is hot-swappable, allowing installation or replacement without operational downtime.
Q3: What input types are compatible with this module?
A3: It supports dry contact and TTL-compatible digital signals for various industrial applications.
Q4: What is the operating temperature range for this module?
A4: The module operates reliably between 0°C and 60°C (32°F to 140°F).
Q5: How does the module handle diagnostics and fault detection?
A5: Built-in diagnostics continuously monitor input channels and alert engineers to potential faults.
Q6: Can it be integrated into redundant FSC control systems?
A6: Yes, the module is fully compatible with FSC redundant architectures for enhanced system reliability.
