Overview
It converts analog and digital signals from smart field transmitters into actionable process data efficiently.
Moreover, the interface maintains signal integrity even in electrically noisy and industrially demanding environments.
Control engineers rely on this module for accurate measurement, rapid response, and seamless integration.
Therefore, it is ideal for systems requiring high reliability, real-time monitoring, and robust process control.
Specification
| Parameter | Specification |
|---|---|
| Manufacturer | Honeywell |
| Model Number | 51304516-200 |
| Product Type | UCN Smart MV Transmitter Interface Card |
| System Compatibility | TDC 3000 Universal Control Network (UCN) |
| Signal Type | Analog 4–20 mA, HART digital |
| Input Voltage | 24 V DC nominal |
| Power Consumption | 4 W typical |
| Communication Protocols | HART 5/6 compatible, Honeywell proprietary |
| Operating Temperature | 0 °C to 60 °C |
| Storage Temperature | –40 °C to +85 °C |
| Humidity | 5% to 95% non-condensing |
| Dimensions | 180 mm × 120 mm × 30 mm |
| Mounting | Panel or rack-mounted |
| LED Indicators | Power, Status, Communication |
| Certifications | CE, UL, CSA approved |
| Weight | 0.52 kg |
FAQ
Q1: Which systems is the 51304516-200 compatible with?
It integrates fully with Honeywell TDC 3000 Universal Control Network systems.
Q2: What types of signals does it support?
It supports analog 4–20 mA signals and HART digital communication.
Q3: Can it operate in industrial environments?
Yes, it performs reliably in temperatures 0–60 °C and humidity 5%–95% non-condensing.
Q4: How easy is installation?
In addition, the module offers plug-and-play card format for quick panel or rack mounting.
Q5: Does it provide diagnostic feedback?
Yes, onboard LEDs display power, communication, and operational status clearly.
Q6: What certifications does this interface card have?
It holds CE, UL, and CSA certifications for industrial deployment.
