Overview
Moreover, it ensures stable voltage regulation for critical automation components, supporting uninterrupted industrial operations.
Engineers choose this module for its robust design and seamless integration with TDC 3000 racks, enhancing system reliability.
In addition, its high-quality construction provides long-term performance under demanding plant conditions.
The module also includes internal protections to safeguard connected devices against power anomalies.
Specification
| Parameter | Specification |
|---|---|
| Model | Honeywell 51198947-200 |
| Module Type | TDC 3000 Power Supply Module |
| Input Voltage | 120/240 VAC, 50/60 Hz |
| Output Voltage | 24 VDC nominal |
| Output Current | 5 A maximum |
| Power Rating | 120 W |
| Fuse | Internal, non-replaceable |
| Hold-up Time | 20 ms at maximum load |
| Wiring Terminals | Screw type, 0.5 mm² – 2.5 mm² |
| Operating Temperature | 0°C to 60°C |
| Storage Temperature | -20°C to 70°C |
| Relative Humidity | 5%–95%, non-condensing |
| Rack Compatibility | Honeywell TDC 3000 I/O and controller racks |
| Protections | Overload, short-circuit, voltage surge protection |
| Typical Applications | Process control, continuous production, industrial automation power supply |
FAQ
Q1: What is the output voltage of the 51198947-200 module?
A1: The module provides a regulated 24 VDC output to TDC 3000 system components.
Q2: Can this power supply handle multiple TDC 3000 I/O modules?
A2: Yes, it is designed to provide stable power across TDC 3000 racks.
Q3: Does the module include overload protection?
A3: Yes, internal protections prevent damage from overloads or short circuits.
Q4: What is the maximum output current?
A4: The maximum output current is 5 A.
Q5: What is the operating temperature range?
A5: It operates reliably from 0°C to 60°C in industrial conditions.
Q6: Is it compatible with all TDC 3000 racks?
A6: Yes, it integrates seamlessly with standard Honeywell TDC 3000 I/O and controller racks.
