Overview
The Bently Nevada 3500/93 135785-01 Display Screen Module delivers clear, real-time visualization for 3500 machinery protection systems. In addition, it provides operators with intuitive access to machinery performance metrics, alarms, and diagnostic information. Moreover, this module integrates seamlessly into standard 3500 system racks, ensuring consistent and reliable operation. Its high-resolution display supports efficient monitoring, reducing the likelihood of operational errors and enabling faster response times.
Specification
| Parameter | Specification |
|---|---|
| Model Number | 3500/93 |
| Part Number | 135785-01 |
| Module Type | Display Screen Module |
| Display Type | High-resolution color LCD |
| Display Size | 12.1 inches diagonal |
| Resolution | 1024 x 768 pixels |
| Aspect Ratio | 4:3 |
| Brightness | 300 cd/m² (typical) |
| Contrast Ratio | 800:1 (typical) |
| Viewing Angle | 160° horizontal / 160° vertical |
| Color Depth | 16.7 million colors |
| Backlight Type | LED backlight |
| Touch Capability | Optional touchscreen interface |
| Input Signals | Proprietary 3500 system bus |
| Output Signals | Visual alarms, operational data display |
| Rack Mount | 19-inch standard 3500 system rack |
| Mounting Depth | 100 mm (standard) |
| Power Supply | 24 VDC ±10% |
| Power Consumption | 25 W typical |
| Operating Temperature | 0°C to 60°C (32°F to 140°F) |
| Storage Temperature | -40°C to 85°C (-40°F to 185°F) |
| Humidity | 5% to 95% non-condensing |
| Shock & Vibration | Per Bently Nevada 3500 system standards |
| Weight | 4.5 kg (9.9 lbs) |
| Compliance | CE, UL listed, RoHS compliant |
| Environmental Protection | IP20, indoor use |
| Connectivity | Proprietary 3500 bus, optional expansion interfaces |
| System Compatibility | Fully compatible with Bently Nevada 3500 series racks and modules |
| Alarms Displayed | Machinery faults, warnings, operational alerts |
| Data Access | Real-time metrics, historical logs, diagnostics |
| Reliability | MTBF > 50,000 hours under normal operating conditions |
