Overview
Configured for signal transmission between the proximity probe and monitoring interface in the 3300 XL vibration monitoring system, the Bently Nevada 330854-080-24-CN (330854 3300 XL 25 mm Extension Cable) provides direct physical connection support for eddy-current measurement circuits.
Hardware Specifications
| Parameter | Specification |
|---|---|
| Model | 330854-080-24-CN |
| Brand | Bently Nevada |
| Product Type | 3300 XL 25 mm Extension Cable |
| Origin | USA |
| Weight | 0.16 kg |
| Dimensions | 20 x 18 x 2 cm (estimated shipping size) |
| Operating Temp | -35 deg C to +85 deg C |
| Storage Temp | -51 deg C to +100 deg C |
| Power Consumption | Passive cable assembly, no external power consumption |
| Cable Length | 8.0 metres (26.2 feet) |
| Cable Type | High Temperature FluidLoc cable |
| Tariff Code | 8537101190 |
Eddy-Current Signal Transmission and Rotor Dynamics Support
The Bently Nevada 330854-080-24-CN extension cable maintains the electrical characteristics required for 3300 XL 25 mm proximity probe systems. The cable transfers probe signals between the sensing element and the monitoring channel while preserving eddy-current probe scaling performance.
In addition, the cable assembly supports gap voltage validation procedures used in TSI applications. The connected monitoring system evaluates probe gap conditions through voltage measurement, with typical setup validation using -10 VDC target gap voltage references.
The FluidLoc cable construction reduces fluid migration risks along the cable path. Therefore, the assembly supports installation conditions where contamination resistance and signal stability are required for rotor dynamics monitoring.
Frequently Asked Questions
Q: What system components connect with the 330854-080-24-CN cable?
A: The cable connects 3300 XL 25 mm proximity probes with compatible Bently Nevada monitoring interfaces within the eddy-current measurement chain.
Q: Does the 330854-080-24-CN extension cable require external power?
A: No. The cable assembly is a passive signal transmission component and does not consume external electrical power.
Q: What environmental conditions does this cable support?
A: The cable operates from -35 deg C to +85 deg C and stores from -51 deg C to +100 deg C according to the provided specifications.
Field Installation Guidelines
Install the extension cable according to the approved 3300 XL proximity system wiring arrangement. Maintain separation from high-voltage power cables and strong electromagnetic interference sources to reduce signal disturbance.
Ensure that cable connectors remain clean and properly secured before commissioning. Avoid excessive bending stress near connector areas because mechanical damage can affect signal transmission quality.
During installation, verify cable routing, shielding continuity, and grounding practices according to the monitoring system installation requirements. Confirm the probe gap voltage after connection to validate correct mechanical positioning and electrical operation.
