Overview
In addition, it enables stable internal logic operations and therefore ensures consistent system behavior in continuous industrial process environments.
Moreover, this board integrates directly into existing TDC 3000 architectures and consequently eliminates the need for configuration changes.
Specification
| Parameter | Specification |
|---|---|
| Manufacturer | Honeywell |
| Model Number | 51400855-100 |
| Product Type | Printed Circuit Board (PC Board) |
| Control System Compatibility | Honeywell TDC 3000 |
| Primary Function | Internal control and signal processing |
| Board Type | System control PCB |
| Installation Location | TDC 3000 rack or cabinet |
| Electrical Interface | Backplane-connected |
| Power Supply | Provided by TDC 3000 system |
| Operating Voltage | System-dependent |
| Signal Handling | Digital control and logic signals |
| Operating Mode | Continuous duty |
| Operating Temperature | 0 °C to 60 °C |
| Storage Temperature | -20 °C to 70 °C |
| Relative Humidity | 5% to 95%, non-condensing |
| Mechanical Form | Standard Honeywell PCB format |
| Mounting Method | Slot-based system mounting |
| Construction | Industrial-grade electronic components |
| Serviceability | Field-replaceable module |
| Compliance | Industrial automation equipment standards |
FAQ
Q1: What is the primary role of the 51400855-100 PC Board?
A1: It supports internal control and signal processing within Honeywell TDC 3000 systems.
Q2: Is this PC board compatible with all TDC 3000 configurations?
A2: Yes, it fits standard TDC 3000 racks and cabinets using the system backplane.
Q3: Does this board require software configuration after installation?
A3: No, it integrates seamlessly with existing system logic and configurations.
Q4: Can this board operate continuously in industrial environments?
A4: Yes, it is designed for continuous duty in demanding process control applications.
Q5: When should this PC board be replaced?
A5: Replacement is recommended during planned maintenance or if electronic performance degrades.
