Overview
It enables precise automation of process sequences, ensuring consistent plant performance.
Moreover, the module supports flexible programming and high-speed execution for complex industrial control applications.
Engineers utilize this PLC module to integrate multiple control loops efficiently, thereby reducing operational errors.
In addition, its robust design provides dependable performance even in electrically noisy and industrially harsh environments.
Specification
| Parameter | Specification |
|---|---|
| Manufacturer | Honeywell |
| Model Number | 51304525-100 |
| Product Type | PLC Module |
| System Compatibility | TDC 3000 Universal Control Network (UCN) |
| Programming Capability | Ladder logic, Boolean logic, sequence control |
| I/O Support | Digital and analog inputs/outputs |
| Processing Speed | Real-time deterministic control |
| Power Supply | 24 V DC nominal |
| Power Consumption | 6 W typical |
| Operating Temperature | 0 °C to 60 °C |
| Storage Temperature | –40 °C to +85 °C |
| Humidity | 5% to 95% non-condensing |
| Dimensions | 200 mm × 120 mm × 40 mm |
| Mounting | Rack-mounted or panel-mounted |
| LED Indicators | Power, Status, Fault |
| Certifications | CE, UL, CSA approved |
| Weight | 0.7 kg |
FAQ
Q1: Which systems is this PLC module compatible with?
It is fully compatible with Honeywell TDC 3000 Universal Control Network systems.
Q2: What programming capabilities does it support?
It supports ladder logic, Boolean logic, and sequence control for complex process automation.
Q3: Can it operate reliably in industrial environments?
Yes, it functions within 0–60 °C and 5–95% non-condensing humidity.
Q4: How is it installed?
The module supports both rack-mounted and panel-mounted installation with plug-and-play connectivity.
Q5: Does it provide diagnostic capabilities?
Yes, LED indicators show power, status, and fault conditions for simplified troubleshooting.
Q6: What certifications does it hold?
The module has CE, UL, and CSA approvals for industrial deployment.
