Overview
The Bently Nevada 161216-01, also cataloged as the 161216-01 Ethernet 10BASE-T/100BASE-TX I/O Module, operates as a dedicated network interface component for Ethernet data communication within the Bently Nevada 3500 Series Rack System using the 3500/91 EGD Gateway Module.
Hardware Specifications
| Parameter | Specification |
|---|---|
| Model | 161216-01 |
| Brand | Bently Nevada (Baker Hughes) |
| Product Type | Ethernet 10BASE-T/100BASE-TX I/O Module |
| Compatible System | Bently Nevada 3500 Series Rack System with 3500/91 EGD Communications Gateway |
| Origin | USA |
| Communication Interface | Ethernet RJ-45 physical network interface |
| Ethernet Standards | IEEE 802.3 10BASE-T, IEEE 802.3u 100BASE-TX, IEEE 802.3 CSMA/CD |
| Supported Network Speeds | 10 Mbps and 100 Mbps |
| Communication Protocols | EGD Version 2.01, Ethernet UDP/IP frame |
| Weight | 0.39 kg |
| Dimensions | 241.3 mm x 24.4 mm x 99.1 mm |
| Operating Temp | -30 deg C to +65 deg C |
| Storage Temp | -40 deg C to +85 deg C |
| Relative Humidity | Up to 95%, non-condensing |
| Power Consumption | Approximately 7.4 Watts typical |
| Connector Type | RJ-45 Ethernet Jack |
| Status Indicators | OK LED, TX/RX LED |
| Certifications | FCC Part 15, EMC Directive 2014/30/EU, LV Directive 2014/35/EU, RoHS |
Ethernet Communication and Machinery Monitoring Data Transfer
The 161216-01 module provides Ethernet communication between the Bently Nevada 3500 rack data environment and external control networks. It transfers rack status information, alarm states, and monitored values through the 3500/91 EGD Communications Gateway interface.
Furthermore, the module supports Ethernet UDP/IP frame communication using EGD Version 2.01. The 10 Mbps and 100 Mbps operating modes allow integration with standard industrial Ethernet infrastructures while maintaining compatibility with existing plant communication systems.
For Bently Nevada machinery monitoring applications, the Ethernet interface maintains data access from vibration, position, speed, and other TSI-related monitoring channels. The module works with processed rack information rather than directly conditioning eddy-current probe signals.
Frequently Asked Questions
Q: Can the Bently Nevada 161216-01 operate as a standalone Ethernet communication module?
A: No. The 161216-01 requires installation within the Bently Nevada 3500 Series Rack System and operates with the 3500/91 EGD Communications Gateway Module.
Q: What Ethernet communication standards does the 161216-01 support?
A: The module supports IEEE 802.3 10BASE-T and IEEE 802.3u 100BASE-TX Ethernet standards with UDP/IP frame communication.
Q: Does the 161216-01 process proximity probe signals directly?
A: No. The module transfers processed monitoring data from the 3500 rack system. Eddy-current probe scaling and gap voltage validation functions are performed by dedicated monitoring modules within the rack.
Field Installation Guidelines
- Install the 161216-01 module in the designated 3500 Series rack slot according to the system hardware configuration requirements.
- Connect the RJ-45 Ethernet interface using industrial Ethernet cabling suitable for the plant network environment.
- Verify that network routing and addressing settings match the connected EGD communication system configuration.
- Separate Ethernet cables from high-voltage power wiring and high-current motor circuits to reduce electrical interference.
- Maintain proper cable shielding and grounding practices according to plant electrical installation standards.
- Confirm OK and TX/RX LED status indicators after power application to verify module operation and communication activity.
