Overview
It provides reliable digital signal acquisition for industrial automation applications.
Moreover, the module ensures accurate, fast response for critical process control systems.
In addition, its compact design allows easy installation in both new and existing control architectures.
Specification
| Parameter | Specification |
|---|---|
| Model | IC697MDL654 |
| Series | GE Series 90-70 |
| Module Type | Discrete Input Module |
| Number of Input Channels | 32 Digital Inputs |
| Input Type | Sinking or Sourcing (compatible with 24V DC field devices) |
| Nominal Input Voltage | 24V DC ± 10% |
| Input Current per Channel | 5–10 mA typical |
| Response Time | 1 ms typical, 2 ms maximum |
| Isolation | Optical isolation between input circuitry and system bus |
| Power Consumption | 2 W typical, 3 W maximum |
| Mounting | Series 90-70 rack, DIN rail compatible |
| Diagnostic Indicators | Individual channel status LEDs, module fault LED |
| Operating Temperature | 0°C to 60°C |
| Storage Temperature | -40°C to 85°C |
| Humidity | 5% to 95% non-condensing |
| Shock & Vibration | 15 g shock, 5–150 Hz vibration (complies with IEC 60068-2-27 / 2-6 standards) |
| Dimensions (H x W x D) | 127 mm x 32 mm x 123 mm |
| Weight | 0.3 kg |
| Certifications | CE, UL, CSA |
| Communication Interface | Series 90-70 proprietary backplane bus |
| Typical Applications | Factory automation, process control, production line monitoring |
| Maintenance | Hot-swappable module; supports 30-day return for quality issues |
FAQ
Q1: Is the IC697MDL654 compatible with all Series 90-70 PLCs?
A1: Yes, it integrates seamlessly with GE Series 90-70 racks and CPUs.
Q2: What is the input voltage range for the module?
A2: It is designed for standard 24V DC discrete input signals.
Q3: How are faults or input status indicated?
A3: Each channel has diagnostic LEDs showing input status and module health.
Q4: Can the module handle high-speed digital inputs?
A4: Yes, the typical response time is 1 ms, suitable for fast industrial processes.
Q5: What is the operating temperature range?
A5: The module operates reliably between 0°C and 60°C.
Q6: What isolation protection does the module provide?
A6: Optical isolation protects the control system from field-side electrical faults.
