Overview
It converts incoming AC power into stable DC outputs required by CPUs, I/O modules, and communication cards.
Moreover, this module supports continuous industrial operation where power stability directly affects system reliability.
Engineers rely on the IC697PWR710 to maintain consistent voltage levels under variable load conditions.
Therefore, it forms a critical foundation for dependable PLC performance in demanding automation environments.
Specification
| Category | Parameter | Specification |
|---|---|---|
| General | Manufacturer | GE Fanuc |
| General | Model Number | IC697PWR710 |
| General | Product Type | PLC Power Supply Module |
| System Series | Compatibility | Series 90-70 PLC |
| Input Power | Input Voltage | 120/240 Vac nominal |
| Input Power | Input Voltage Range | 85–264 Vac |
| Input Power | Input Frequency | 47–63 Hz |
| Input Power | Input Current | 4.2 A max @ 120 Vac, 2.1 A max @ 240 Vac |
| Output Power | Primary Output Voltage | 5 Vdc regulated |
| Output Power | Primary Output Current | Up to 30 A continuous |
| Output Power | Auxiliary Output Voltage | 24 Vdc for relay logic (1 A max) |
| Output Power | Total Power Capacity | 150 W nominal DC output |
| Regulation | Voltage Regulation | ±2% under full load |
| Ripple & Noise | Output Ripple | <50 mV peak-to-peak |
| Protection | Overcurrent Protection | Foldback or electronic current limiting |
| Protection | Short-Circuit Protection | Fully protected, automatic recovery |
| Protection | Thermal Protection | Internal over-temperature shutdown |
| Mechanical | Mounting Type | Rack-mounted on standard 90-70 backplane |
| Mechanical | Dimensions (H × W × D) | 12.2 × 3.5 × 10 in (31 × 8.9 × 25.4 cm) |
| Mechanical | Weight | 12 lbs (5.4 kg) |
| Indicators | LEDs | Power OK / Fault / Output Status |
| Environmental | Operating Temperature | 0 °C to +60 °C |
| Environmental | Storage Temperature | –40 °C to +85 °C |
| Environmental | Relative Humidity | 5–95% non-condensing |
| Environmental | Vibration | IEC 68-2-6, 5–500 Hz, 2 g |
| Reliability | MTBF | >100,000 hours at rated load |
| Certifications | Safety Compliance | UL, CE, CSA certified |
| Service | Maintenance | Hot-swapable replacement recommended by OEM |
FAQ
A1: It is designed specifically for GE Fanuc Series 90-70 PLC systems.
Q2: What input voltage does the IC697PWR710 require?
A2: The module supports standard industrial 120 Vac or 240 Vac power inputs.
Q3: Can this power supply support a fully populated PLC rack?
A3: Yes, its high current 5 Vdc output supports fully configured Series 90-70 racks.
Q4: Is the IC697PWR710 suitable for continuous operation?
A4: Yes, it is engineered for continuous-duty industrial automation environments.
