Overview
It enables flexible configuration of up to five slots, supporting digital, analog, and specialty modules simultaneously.
Therefore, industrial control systems achieve scalable and maintainable hardware integration.This baseplate belongs to GE’s Series 90-30 family, recognized for rugged reliability in automation applications.
Moreover, the IC693CHS397 ensures consistent backplane connectivity, reducing signal errors and improving overall system uptime.
As a result, operators can expand control architectures efficiently without compromising performance.
Specification
| Parameter | Specification |
|---|---|
| Model Number | IC693CHS397 |
| Manufacturer | General Electric (GE) |
| Series | Series 90-30 |
| Product Type | 5-Slot Modular CPU Baseplate |
| Number of Slots | 5 (supports CPU, digital, analog, and specialty modules) |
| Slot Pitch | 20 mm per slot (standard Series 90-30 spacing) |
| Backplane Bus | Proprietary Series 90-30 backplane with 32-bit data bus |
| Module Compatibility | Supports IC693CPU, IC693ALG, IC693DI, IC693DO, IC693MDL modules |
| Communication | Internal backplane for module-to-module communication |
| Maximum Module Height | 120 mm |
| Maximum Module Depth | 80 mm |
| Power Supply Connection | Receives +5 V, +12 V, +24 V from Series 90-30 power module |
| Energy Storage | Internal capacitors for module initialization; no user-replaceable batteries |
| Mounting Options | DIN-rail, panel mount, or chassis integration |
| Operating Temperature | 0 °C to +60 °C |
| Storage Temperature | −25 °C to +70 °C |
| Relative Humidity | 5–95% non-condensing |
| Shock and Vibration | IEC 60068-2-6 / IEC 60068-2-27 tested for industrial environments |
| Materials | Industrial-grade plastics and metals for durability and electrical insulation |
| Weight | Approx. 1.2 kg |
| Dimensions (H × W × D) | 120 mm × 150 mm × 80 mm |
| Typical Applications | Modular industrial automation, process control, manufacturing system I/O expansion |
| Compliance | Meets UL, CE, and industrial control safety standards |
| Diagnostics | Supports Series 90-30 backplane diagnostics for module status monitoring |
| Cooling | Natural convection; no active cooling required |
| Expansion Capability | Can cascade multiple baseplates for larger I/O systems |
FAQ
Q1: Is the IC693CHS397 brand new and original?
A1: Yes, the GE IC693CHS397 is full new, original, and factory-sealed.
Q2: Do you have this Series 90-30 baseplate in stock?
A2: Yes, we maintain inventory for immediate order fulfillment.
Q3: How fast can it be shipped?
A3: Shipping typically takes 3 days to 2 weeks, depending on order size and destination.
Q4: Which logistics carriers do you use?
A4: We commonly ship via DHL, FedEx, UPS, and other major international couriers.
Q5: How many modules can this baseplate support?
A5: The IC693CHS397 accommodates up to five Series 90-30 CPU or I/O modules.
Q6: What if a quality issue occurs after delivery?
A6: We support 30-day returns for any verified quality-related problems.
