Overview
Specification
| Parameter | Specification |
|---|---|
| Model | IC200CPU001 |
| Module Type | VersaMax CPU Module |
| Processor | 16-bit microprocessor, high-speed deterministic execution |
| User Memory | 16 KB, stores user programs and variables |
| System Memory | 32 KB, firmware and system operation data |
| Program Storage | Non-volatile memory, retains program during power loss |
| Maximum I/O Points | Up to 256 points via VersaMax digital and analog modules |
| Digital I/O Scan Rate | 2 ms per 100 instructions (typical) |
| Analog I/O Support | 0–10 V, 4–20 mA inputs, compatible with VersaMax analog modules |
| Communication Interfaces | DH+ (Data Highway Plus), Modbus RTU for PLC and HMI/SCADA integration |
| Power Supply | 5 VDC ±5%, 1.3 A typical |
| Power Consumption | Approximately 6.5 W under normal operation |
| Operating Temperature | 0°C to 60°C (32°F to 140°F) |
| Storage Temperature | -40°C to 85°C (-40°F to 185°F) |
| Relative Humidity | 5% to 95% (non-condensing) |
| Mounting | DIN rail or panel mount for flexible installation |
| Dimensions | 122 mm (H) x 112 mm (W) x 35 mm (D) |
| Certifications | CE, UL Listed |
| Status Indicators | LEDs for RUN, ERROR, COMM, providing operational monitoring |
| Redundancy | Optional backup CPU for enhanced system reliability |
| Firmware Upgrade | Via PC or network, simplifies maintenance and feature updates |
| Environmental Protection | Robust design resists vibration and electrical noise |
| Typical Applications | Factory automation, process control, packaging, material handling |
FAQ
Yes, it can manage up to 256 I/O points with compatible VersaMax modules.Q2: Which communication protocols are supported?
The module supports DH+ and Modbus protocols for flexible network integration.
Q3: What is the typical processing speed?
It executes approximately 100 instructions in 2 milliseconds under standard conditions.
Q4: Can it operate in harsh industrial environments?
Yes, it functions reliably within 0°C to 60°C, and its robust design withstands vibrations and power fluctuations.
Q5: Is technical support available?
Yes, both local and international technical support, firmware updates, and documentation are available.
