Overview
Specification
| Parameter | Description |
|---|---|
| Model | UR-RHH / URRHH / UR RHH |
| Manufacturer | GE Fanuc Multilin |
| Product Type | Power Supply Module |
| Input Voltage Range | 85–264 VAC or 125–250 VDC |
| Output Voltage | 24 VDC regulated (nominal) |
| Power Output | Up to 100 W continuous |
| Efficiency | >85% typical |
| Isolation Voltage | 2.5 kV RMS (input to output) |
| Protection Features | Overvoltage, short circuit, thermal shutdown |
| Cooling Method | Convection cooled, no external fans required |
| Operating Temperature | −40°C to +85°C |
| Storage Temperature | −55°C to +105°C |
| Humidity Range | Up to 95% non-condensing |
| Mounting | Plug-in UR chassis slot |
| Certifications | UL, CE, CSA, IEC 60255 compliance |
| Compatibility | Compatible with all GE Multilin UR-series relays (e.g., UR-9EH, UR-8HH) |
FAQ
A1: It supplies stable DC power to the GE Multilin UR Series relay system.Q2: Can the UR-RHH operate with both AC and DC input sources?
A2: Yes, it supports a universal input range from 85–264 VAC or 125–250 VDC.
Q3: Is the UR-RHH module hot-swappable?
A3: Yes, users can replace it during operation without shutting down the entire relay chassis.
Q4: What protection features are built into the UR-RHH?
A4: It includes overvoltage, overcurrent, and temperature protection circuits.
Q5: Which UR-series modules is it compatible with?
A5: It integrates seamlessly with CPU, I/O, and communication modules in the GE Multilin UR family.
