Overview
Moreover, this module supports demanding industrial loads while maintaining stable switching performance and predictable response behavior.
In addition, GE designed IC693MDL752 to integrate smoothly with existing Series 90-30 baseplates and control architectures.
Specification
| Parameter | Specification |
|---|---|
| Manufacturer | General Electric (GE) |
| Model | IC693MDL752 |
| Series | Series 90-30 |
| Module Type | Discrete DC Output Module |
| Output Points | 32 points |
| Output Configuration | Positive logic (sourcing) |
| Output Voltage (Nominal) | 24 VDC |
| Operating Voltage Range | 12–30 VDC |
| Output Current per Point | 0.5 A maximum |
| Maximum Current per Module | 8 A total (sum of all points) |
| Output Protection | Electronic current limiting and short-circuit protection |
| Output Response Time | 1.5–2 ms typical switching time |
| Output Status Indicators | Individual LED per output |
| Isolation | Full galvanic isolation between field wiring and backplane |
| Field Wiring Terminals | Removable screw-type terminal block |
| Acceptable Wire Size | 14–22 AWG (2.0–0.34 mm²) |
| Backplane Current Consumption | 5 VDC @ ~300 mA |
| Power Dissipation | ~4 W maximum under full load |
| Energy Storage | None |
| Backplane Interface | Series 90-30 backplane slot |
| Mounting | Standard Series 90-30 baseplate |
| Dimensions (H × W × D) | 102 × 34 × 81 mm (approx.) |
| Weight | 0.32 kg (approx.) |
| Operating Temperature | 0–60 °C (32–140 °F) |
| Storage Temperature | −40–85 °C (−40–185 °F) |
| Relative Humidity | 5–95% non-condensing |
| Vibration Resistance | 10–58 Hz: 0.15 mm peak; 58–500 Hz: 5 g peak |
| Shock Resistance | 10 g, 11 ms half-sine pulse |
| Compliance | UL, CE, RoHS |
| Typical Applications | Actuator control, solenoids, relays, signal indicators in manufacturing, conveyors, and automated systems |
