Overview
Specification
| Parameter | Specification |
|---|---|
| Model | IC697MDL350 |
| Series | GE Series 90-70 |
| Module Type | 32-Point Discrete Output Module |
| Number of Output Channels | 32 |
| Output Type | Sinking or Sourcing |
| Nominal Output Voltage | 24V DC ± 10% |
| Output Current per Channel | 0.5 A maximum |
| Response Time | 1 ms typical, 2 ms maximum |
| Isolation | Optical isolation between outputs and system bus |
| Power Consumption | 2.5 W typical |
| Mounting | Series 90-70 rack, DIN rail compatible |
| Diagnostic Indicators | Individual channel LEDs, module fault LED |
| Operating Temperature | 0°C to 60°C |
| Storage Temperature | -40°C to 85°C |
| Humidity | 5% to 95% non-condensing |
| Shock & Vibration | 15 g shock, 5–150 Hz vibration (IEC 60068-2-27 / 2-6 compliant) |
| Dimensions (H x W x D) | 127 mm x 32 mm x 123 mm |
| Weight | 0.3 kg |
| Certifications | CE, UL, CSA |
| Communication Interface | Series 90-70 proprietary backplane bus |
| Typical Applications | Factory automation, process control, discrete device management |
| Maintenance | Hot-swappable; supports 30-day return for quality issues |
FAQ
Q1: Is the IC697MDL350 module brand new and original?
A1: Yes, the IC697MDL350 is 100% original from GE and comes fully factory-sealed.
Q2: What is the typical delivery time for this module?
A2: We ship from 3 days up to 2 weeks depending on order quantity and logistics method.
Q3: Which PLC systems is this module compatible with?
A3: The module is compatible with GE Series 90-70 PLC racks and related control systems.
Q4: Can this module handle high-speed signal switching?
A4: Yes, the IC697MDL350 supports fast discrete output operations for precise control.
Q5: What warranty or return policy applies if the module has quality issues?
A5: We support returns within 30 days for any quality or manufacturing defects.
Q6: Can the module be integrated into existing factory automation setups?
A6: Absolutely. Engineers can easily integrate it into existing PLC racks to enhance system efficiency.
