Overview
Suffix Breakdown & Model Matrix
| Parameter | Specification |
|---|---|
| Product No. | 3500/15-05-05-00 |
| Product Type | 3500/15 AC and DC Power Supplies |
| Base Model | 3500/15 |
| Power Supply Configuration | 05 |
| Input Voltage | 85 to 264 Vac rms |
| Agency Approval Option | 00 – None |
| Product Function | Power Supply Module |
Hardware Specifications
| Parameter | Specification |
|---|---|
| Model | 3500/15E |
| Brand | Bently Nevada |
| Origin | USA |
| Product Parameters | Power Supply Module |
| Weight | 1.42 kg |
| Dimensions | Estimated shipping size: 5.5 x 29 x 23 cm |
| Operating Temp | -30 deg C to +65 deg C |
| Storage Temp | -40 deg C to +85 deg C |
| Humidity | 95%, non-condensing |
| Input Voltage | 85 to 264 Vac rms |
Bently Nevada 3500 Power Architecture
The 3500/15 functions as a dedicated power supply module within the 3500 system architecture. Therefore, installation must maintain the specified electrical input path and mechanical module position.
The supplied configuration identifies universal AC input from 85 to 264 Vac rms. However, the provided data does not specify output voltage, output current, backplane current consumption, or redundancy switching characteristics.
The environmental specification permits operation from -30 deg C to +65 deg C. In addition, the stated storage range extends from -40 deg C to +85 deg C, with humidity specified at 95%, non-condensing.
Frequently Asked Questions
Q: What AC input range does the 3500/15-05-05-00 support?
A: The specified power supply configuration accepts 85 to 264 Vac rms universal AC input.
Q: Does the supplied model include an agency approval option?
A: No. The product suffix identifies agency approval option 00, specified as none.
Q: Can the supplied data confirm the power supply output rating?
A: No. The provided information does not specify output voltage, output current, or total power output.
Field Installation Guidelines
- Verify the product number and module configuration before installation.
- Confirm that the installed AC source remains within the specified 85 to 264 Vac rms input range.
- Isolate and lock out the power source before connecting or removing the module.
- Install the module in the designated 3500 system position and ensure proper mechanical seating.
- Keep power wiring physically separated from low-level vibration, transducer, and communication wiring where practical.
- Route field wiring to prevent mechanical stress on terminals and connectors.
- Maintain appropriate protective earthing and follow the installation requirements of the host 3500 system.
- Do not infer output ratings or backplane loading from the input voltage specification.
- Confirm ambient temperature and humidity conditions remain within the stated operating limits.
- Inspect connectors and wiring for damage before energizing the system.
