Overview
Hardware Specifications
| Parameter | Specification |
|---|---|
| Model | 330130-030-00-05 |
| Brand | Bently Nevada |
| Product Type | 3300 XL Standard Extension Cable |
| Origin | USA |
| Weight | 0.22 kg |
| Dimensions | 20.4 x 22.2 x 3.5 cm (shipping size) |
| Operating Temp | Not specified |
| Power Consumption | Passive cable component, no external power consumption |
| Cable Length | 3.0 meters (9.8 feet) |
| Cable Type | Standard cable |
| Connector Protector Option | Standard configuration |
| Agency Approvals | CSA, ATEX, IECEx |
| Tariff Code | 8537101190 |
Eddy-Current Probe Signal Transmission Characteristics
The 330130-030-00-05 extension cable transfers proximity probe signals within the 3300 XL monitoring chain. It maintains the electrical connection between the probe and compatible monitoring hardware while supporting eddy-current probe scaling functions.
Moreover, the cable assembly maintains signal integrity for rotor position and vibration measurement circuits. The extension cable design supports gap voltage validation requirements, including typical -10 VDC target monitoring conditions used in proximity measurement systems.
The cable construction also supports cross-talk suppression practices by maintaining controlled routing and shielding between measurement channels. Therefore, correct installation reduces unwanted interference in TSI and mechanical monitoring applications.
Frequently Asked Questions
Q: What is the main function of the Bently Nevada 330130-030-00-05?
A: The cable extends the connection between a 3300 XL proximity probe and compatible monitoring equipment for eddy-current measurement signal transmission.
Q: Does the 330130-030-00-05 require an external power supply?
A: No. The extension cable is a passive electrical component and does not consume external power.
Q: Which approval standards apply to this cable assembly?
A: This model supports CSA, ATEX, and IECEx agency approval options for applicable installation environments.
Field Installation Guidelines
Install the 330130-030-00-05 cable according to the Bently Nevada 3300 XL system wiring requirements. Route the cable away from high-current power conductors and strong electromagnetic interference sources.
Maintain proper shield termination practices at the designated connection points. Avoid excessive bending, mechanical stress, or unauthorized cable modifications that may affect signal characteristics.
Verify connector engagement before system operation. Confirm the complete proximity measurement loop, including probe, extension cable, and monitoring module connections, before performing vibration or position measurements.
