Overview
Hardware Specifications
| Parameter | Specification |
|---|---|
| Model | 330101-00-10-10-02-00 |
| Brand | Bently Nevada |
| Product Type | 3300 XL 8 mm Proximity Probe |
| Origin | USA |
| Weight | 0.1 kg |
| Dimensions | 104 x 1.5 x 1.2 cm shipping size |
| Probe Thread Type | 3/8-24 UNF thread |
| Probe Armor Option | Without armor |
| Unthreaded Length Option | 0.0 in |
| Overall Case Length Option | 1.0 in |
| Total Length | 1.0 meter (3.3 feet) |
| Connector Type | Miniature coaxial ClickLoc connector standard cable |
| Application Series | 3300 XL 8 mm Proximity Probe System |
Eddy-Current Probe Scaling and Gap Voltage Validation
The 330101-00-10-10-02-00 uses eddy-current probe technology to measure relative shaft displacement through electromagnetic field variation between the probe tip and the rotating target surface. Moreover, the probe output follows the calibrated scaling characteristics of the 3300 XL 8 mm proximity measurement system.
The probe installation requires correct mechanical positioning to maintain the specified electrical gap range. Therefore, technicians verify gap voltage during commissioning procedures, with Bently Nevada systems typically using -10 VDC target gap voltage for probe setup validation.
The probe design supports rotor dynamics monitoring by providing displacement signals required for vibration analysis, shaft position measurement, and machine condition evaluation. In addition, the miniature coaxial ClickLoc connector cable configuration maintains signal transmission integrity between the probe and monitoring electronics.
Frequently Asked Questions
Q: What connection type does the 330101-00-10-10-02-00 proximity probe use?
A: The probe uses a miniature coaxial ClickLoc connector with a standard cable configuration.
Q: What mechanical thread specification does this probe provide?
A: The probe provides a 3/8-24 UNF thread and uses a 0.0 in minimum unthreaded length option with a 1.0 in case length option.
Q: Does this model include agency approval options?
A: No. The supplied configuration specifies that agency approval is not required.
Field Installation Guidelines
Install the 330101-00-10-10-02-00 probe according to the mechanical clearance requirements of the monitored rotating equipment. Verify that the probe tip maintains correct alignment with the target surface before final tightening.
Use appropriate cable routing practices to reduce mechanical stress and avoid placing the coaxial cable near high-noise electrical sources. Additionally, maintain proper shielding and grounding practices according to the Bently Nevada monitoring system installation requirements.
During commissioning, check probe output polarity, gap voltage, and signal response before connecting the channel to the monitoring module. Avoid excessive bending or pulling force on the miniature coaxial ClickLoc connector cable to prevent signal degradation.
