Overview
It delivers fast logic execution and, moreover, supports large-scale, mission-critical industrial automation applications efficiently.
In addition, this CPU module provides reliable control and integrates seamlessly with existing 90-70 backplane architectures, ensuring smooth operation.
Furthermore, IC697CPX772 enables hot-standby redundancy configurations, which allow continuous system operation without interruption.
Therefore, engineers choose this module to achieve high availability, precise timing, and robust network communications across complex industrial systems.
Specification
| Category | Parameter | Specification |
|---|---|---|
| Manufacturer | Brand | GE Automation |
| Model | Product Number | IC697CPX772 |
| Module Type | Function | Series 90-70 CPU Module |
| System Compatibility | Controller | Series 90-70 PLC |
| Processor | Type | High-speed 32-bit processor |
| Memory | RAM | 4 MB standard, expandable |
| Memory | Program Storage | 2 MB Flash memory |
| Redundancy | Supported | Hot-standby dual CPU configuration |
| Backplane | Communication | Series 90-70 backplane interface |
| Ports | Ethernet | 10/100 Mbps RJ45 |
| Ports | Serial | RS-232/RS-485 for serial communication |
| I/O Support | Max I/O Modules | Up to 256 modules per system |
| Timing | Clock Accuracy | ±1 ppm, battery-backed |
| Power Requirements | Voltage | 5 Vdc from backplane |
| Power Requirements | Consumption | 35 W typical |
| Mechanical | Mounting | Rack-mounted, Series 90-70 backplane |
| Mechanical | Dimensions | 12.7 cm × 4.0 cm × 15.0 cm |
| Mechanical | Weight | 1.5 kg (approx. 3.3 lbs) |
| Environmental | Operating Temperature | 0–60 °C |
| Environmental | Storage Temperature | –40–85 °C |
| Environmental | Humidity | 5–95% non-condensing |
| Certifications | Standards | UL, CE, CSA approved |
| Reliability | MTBF | >100,000 hours at rated load |
FAQ
A1: Yes, it supports dual CPU hot-standby configurations for uninterrupted industrial control.
Q2: What processor type is included in this CPU?
A2: The module features a high-speed 32-bit processor for fast logic execution and multitasking.
Q3: How much memory is available?
A3: It provides 4 MB RAM and 2 MB Flash program storage for large-scale applications.
Q4: Which communication ports are available?
A4: Ethernet 10/100 Mbps RJ45 and RS-232/RS-485 serial ports are included.
Q5: Can it operate reliably in industrial environments?
A5: Yes, it operates in 0–60 °C temperatures and 5–95% non-condensing humidity.
