Overview
It provides reliable switching of digital outputs and supports high-speed industrial automation applications.
Moreover, this module integrates seamlessly with standard Series 90-70 backplanes, allowing flexible rack configurations.
In addition, IC697MDL750 ensures precise signal control while maintaining consistent performance across multiple industrial processes.
Therefore, engineers rely on this output module to expand system capabilities with minimal installation complexity.
Specification
| Category | Parameter | Specification |
|---|---|---|
| Manufacturer | Brand | GE Automation |
| Model | Product Number | IC697MDL750 |
| Module Type | Function | 32-Point Output Module |
| System Compatibility | Controller | Series 90-70 PLC |
| Outputs | Points | 32 discrete digital outputs |
| Outputs | Type | Relay / Transistor compatible |
| Outputs | Current Rating | 0.5 A per point maximum |
| Outputs | Voltage Rating | 5–120 Vdc or 24–120 Vac |
| Interface | Communication | Series 90-70 backplane |
| Isolation | Protection | Optical isolation between channels |
| Timing | Switching Speed | 2 ms typical per point |
| Power Requirements | Voltage | 5 Vdc from backplane |
| Power Requirements | Consumption | 5 W typical |
| Mechanical | Mounting | Rack-mounted, Series 90-70 backplane |
| Mechanical | Dimensions | 12.7 cm × 4.0 cm × 15.0 cm |
| Mechanical | Weight | 1.2 kg (approx. 2.6 lbs) |
| Environmental | Operating Temperature | 0–60 °C |
| Environmental | Storage Temperature | –40–85 °C |
| Environmental | Humidity | 5–95% non-condensing |
| Certifications | Standards | UL, CE, CSA approved |
FAQ
A1: Yes, it is fully compatible with Series 90-70 backplanes and standard PLC racks.
Q2: How many outputs does this module provide?
A2: IC697MDL750 offers 32 discrete digital output points with fast switching.
Q3: What is the maximum output current per point?
A3: Each output supports up to 0.5 A, depending on voltage and load type.
Q4: Can it handle both AC and DC loads?
A4: Yes, it supports 5–120 Vdc and 24–120 Vac applications.
Q5: How quickly can the outputs switch?
A5: Switching speed is typically 2 milliseconds per point under normal conditions.
Q6: What is your delivery and return policy?
A6: All units are new and genuine. Stock is available, with shipping in 3 days–2 weeks. Returns are supported within 30 days if quality issues occur.
