Overview
It accepts voltage and current inputs, converting them to digital values for PLC processing.
Moreover, the module ensures reliable operation under industrial conditions, supporting precise process control applications.In addition, IC695ALG616 integrates seamlessly with Rx3i control racks, reducing configuration complexity.
Therefore, engineers rely on it for consistent performance in demanding manufacturing and automation environments.
Specification
| Category | Parameter | Specification |
|---|---|---|
| Manufacturer | Brand | GE Automation |
| Model | Product Number | IC695ALG616 |
| Module Type | Function | Analog Input Module |
| System Compatibility | Controller | Rx3i PacSystem |
| Channels | Number of Inputs | 16 single-ended or 8 differential |
| Input Types | Voltage Range | ±10 V, 0–10 V selectable |
| Input Types | Current Range | 0–20 mA, 4–20 mA |
| Input Types | Thermocouple Support | J, K, T, E, R, S, B types |
| Resolution | A/D Converter | 16-bit |
| Sampling Rate | Conversion Rate | 10 kS/s per channel |
| Isolation | Channel-to-Channel | 1500 V rms optical isolation |
| Isolation | Channel-to-Backplane | 1500 V rms |
| Accuracy | Typical | ±0.1% of full scale |
| Linearity | Max | ±0.05% |
| Response Time | Typical | 0.5 ms per channel |
| Power Requirements | Voltage | 5 Vdc from backplane |
| Power Requirements | Consumption | 2.5 W typical |
| Mechanical | Mounting | Rack-mounted, Rx3i standard backplane |
| Mechanical | Dimensions | 12.7 cm × 3.8 cm × 14.6 cm |
| Environmental | Operating Temp | 0–60 °C |
| Environmental | Storage Temp | –40–85 °C |
| Environmental | Humidity | 5–95% non-condensing |
| Certifications | Standards | UL, CE, CSA approved |
FAQ
A1: It supports 16 single-ended or 8 differential analog input channels.Q2: What input types are compatible?
A2: It accepts 0–10 V, ±10 V, 0–20 mA, 4–20 mA, and thermocouple signals.Q3: What is the module’s resolution?
A3: The IC695ALG616 provides 16-bit analog-to-digital conversion for high precision.
Q4: Can it operate in harsh industrial environments?
A4: Yes, it supports 0–60 °C operating temperature and 5–95% non-condensing humidity.
Q5: Is the module compatible with older Rx3i systems?
A5: Yes, it integrates seamlessly into standard Rx3i PacSystem backplanes.
