Overview
It provides reliable control for industrial automation processes, ensuring fast execution of complex logic.
Engineers rely on this CPU for precise machine control, data acquisition, and seamless communication with I/O modules.
Moreover, its compact design allows integration into dense PLC racks without sacrificing performance.
This module supports advanced programming and diagnostics, enhancing system efficiency and reducing commissioning time.
Therefore, it is widely used in manufacturing, process control, and critical automation environments where uptime is essential.
Specification
| Parameter | Specification |
|---|---|
| Manufacturer | GE Fanuc Automation |
| Product Series | Series 90-30 PLC |
| Model Number | IC693CPU364 |
| Module Type | Single-Slot CPU Module |
| CPU Architecture | 16-bit microprocessor |
| Instruction Execution Time | 0.50 μs per basic instruction |
| User Program Memory | 96 KB (program) |
| Data Memory | 16 KB (data) |
| Maximum I/O Capacity | 256 I/O points (backplane + remote I/O) |
| I/O Expansion | Supports additional I/O modules via Series 90-30 racks |
| Internal Communication | Dual serial ports (RS-232/RS-485) |
| Networking | Supports multi-drop PLC network configurations |
| Scan Time | Approx. 1.3 ms per 1000 instructions |
| Operating Modes | Run, Program, Test |
| Status Indicators | Power, Run, Fault, I/O Status LEDs |
| Programming Languages | GE PLC programming languages (Ladder Logic, Structured Text) |
| Power Supply | 5 V DC from backplane |
| Power Consumption | Approx. 5 W typical |
| Operating Temperature | 0°C to 60°C |
| Storage Temperature | -40°C to 85°C |
| Relative Humidity | 5% to 95%, non-condensing |
| Vibration / Shock Resistance | IEC 60068-2 compliant |
| Mounting | Rack-mounted, single-slot module |
| Certifications / Compliance | CE, UL recognized, industrial automation standards |
| Diagnostics | Built-in self-test, fault detection, and status monitoring |
| Typical Applications | Process control, manufacturing automation, assembly lines, packaging systems, material handling |
FAQ
Q1: What PLC series is the IC693CPU364 compatible with?
A1: It is compatible with the GE Series 90-30 PLC platform and supports related I/O modules.
Q2: Can this CPU handle high-speed control tasks?
A2: Yes, it executes instructions at 0.50 μs per basic instruction for fast, deterministic performance.
Q3: What communication options are available?
A3: The module includes dual RS-232/RS-485 ports for networked PLC communication.
Q4: How much program memory does the CPU provide?
A4: It has 96 KB of user program memory and 16 KB of data memory for complex logic.
Q5: Is it suitable for process control and manufacturing applications?
A5: Yes, it is ideal for process control, assembly lines, packaging systems, and material handling.
Q6: Does the module support system expansion?
A6: Yes, it allows integration of additional I/O modules and specialty cards for flexible system design.
