Overview
Specification
| Parameter | Specification |
|---|---|
| Model Number | 330500-06-00 |
| Sensor Type | Piezoelectric Velocity Sensor (Velomitor) |
| Measurement Range | 0–50 in/s (0–1270 mm/s) |
| Frequency Response | 2 Hz to 10 kHz |
| Sensitivity | 100 mV/in/s nominal |
| Transverse Sensitivity | <5% typical |
| Linearity | ±1% full-scale typical |
| Operating Temperature | -40°C to 120°C (-40°F to 248°F) |
| Storage Temperature | -55°C to 125°C (-67°F to 257°F) |
| Shock Resistance | 100 g, 1 ms half-sine |
| Vibration Resistance | 50 g, 10–500 Hz |
| Cable | 3 meters standard, custom lengths available |
| Connector | MIL-C-26482 compatible or custom termination |
| Mounting | ¼-28 UNF threaded stud or optional clamp |
| Housing Material | Stainless steel, hermetically sealed |
| System Compatibility | Bently Nevada 3300 Machinery Protection System |
| Weight | Approx. 0.25 kg |
| Environmental Protection | IP65 / NEMA 4 |
FAQ
A1: It measures vibration velocity to detect imbalance, misalignment, and machinery faults.
Q2: Can it operate in high-temperature industrial environments?
A2: Yes, it operates reliably from -40°C to 120°C (-40°F to 248°F).
Q3: Is it compatible with Bently Nevada 3300 monitoring systems?
A3: Absolutely. It integrates seamlessly for real-time machinery vibration monitoring.
Q4: How does this sensor support predictive maintenance?
A4: Continuous vibration velocity data allows early detection of potential machinery issues.
Q5: Can cable lengths be customized for installation?
A5: Yes, the standard 3-meter cable can be extended or modified as needed.
Q6: What makes this sensor durable in harsh industrial environments?
A6: Stainless steel housing, hermetic sealing, and shock/vibration resistance ensure long-term reliability.
