Overview
In addition, the 3300 XL platform is trusted worldwide for long-term stability, repeatability, and conformity with machinery protection standards. Furthermore, its rugged design ensures consistent performance even in harsh industrial environments.
Specification
| Parameter | Specification |
|---|---|
| Manufacturer | Bently Nevada (Baker Hughes) |
| Model Number | 330100‑90‑02 |
| Series | 3300 XL |
| Product Type | Proximitor Sensor / Proximity Transducer |
| Compatible Probe | 8 mm 3300 XL proximity probes |
| Measurement Principle | Non-contact eddy current displacement sensing |
| Output Signal | Analog voltage proportional to displacement |
| Measurement Range | Up to ~2 mm system range |
| Sensitivity | ~7.87 V/mm typical for 8 mm system |
| Frequency Response | Suitable for continuous vibration and position monitoring |
| Power Supply | -17.5 Vdc to -26 Vdc (nominal -24 Vdc) |
| Current Consumption | Low-power, continuous-duty design |
| Mounting | Panel or DIN-rail mount |
| Environmental Rating | Industrial control cabinet environment |
| Connector Type | Click-Lok or equivalent secure connectors |
| Service Life | Designed for long-term industrial operation |
FAQ
A1: It converts proximity probe signals into stable voltage outputs for vibration and position monitoring.Q2: Which probes are compatible with this sensor?
A2: It is designed for use with Bently Nevada 8 mm 3300 XL proximity probes.
Q3: Can this sensor operate continuously in vibration monitoring applications?
A3: Yes, it is engineered for continuous operation in critical rotating machinery.
Q4: Does this sensor require field calibration after installation?
A4: No, factory calibration ensures plug-and-play performance with approved probes.
Q5: What industries commonly use this Proximitor Sensor?
A5: Power generation, oil and gas, petrochemical, and heavy industrial facilities.
Q6: Is it compliant with API 670 requirements?
A6: When installed in a qualified 3300 XL system, it meets applicable API 670 standards.
