Overview
It provides accurate voltage and current signals to control industrial actuators and devices reliably.
Moreover, the module features fast update rates and stable output conversion, ensuring consistent process performance.
Therefore, engineers choose IC697VAL314 for demanding automation systems that require precise analog control.
Specification
| Parameter | Specification |
|---|---|
| Manufacturer | GE Fanuc / GE Automation |
| Product Series | Series 90-70 PLC |
| Model Number | IC697VAL314 |
| Module Type | Analog Output Module |
| Output Channels | 4 isolated analog outputs |
| Output Signal Types | Voltage: ±10 VDC, 0–10 VDC; Current: 4–20 mA |
| Output Resolution | 12-bit or higher D/A conversion |
| Output Accuracy | ±0.25% of full scale typical |
| Output Update Rate | 5 ms per channel typical |
| Channel Isolation | Channel-to-channel and channel-to-backplane isolation |
| Overvoltage Protection | Yes, protects module and connected devices |
| Short-Circuit Protection | Yes, built-in per channel |
| Diagnostics | Channel status, fault detection via PLC diagnostics |
| User Memory | Not applicable (analog output module) |
| Backplane Power Supply | +5 VDC and +12 VDC from Series 90-70 backplane |
| Power Consumption | Typical < 3 W |
| Operating Temperature | 0 °C to 60 °C (32 °F to 140 °F) |
| Storage Temperature | −40 °C to 85 °C |
| Relative Humidity | 5% to 95%, non-condensing |
| Vibration Resistance | Meets GE industrial specifications for Series 90-70 modules |
| Module Housing | Standard Series 90-70 industrial enclosure |
| Module Dimensions | Fits single Series 90-70 PLC rack slot |
| Mounting Method | Series 90-70 PLC rack installation |
| Typical Applications | Control valves, motor speed regulation, analog actuators, industrial automation |
| Lifecycle Status | Mature product, widely deployed in industrial environments |
