Overview
It provides reliable control of industrial loads through isolated solid-state or relay outputs.
Moreover, the module supports fast switching and precise output timing, ensuring accurate process control.
Therefore, engineers rely on IC697MDL340 for mission-critical automation applications in complex industrial environments.
Specification
| Parameter | Specification |
|---|---|
| Manufacturer | GE Fanuc / GE Automation |
| Product Series | Series 90-70 PLC |
| Model Number | IC697MDL340 |
| Module Type | Digital Output Module |
| Output Channels | 8 independent isolated digital outputs |
| Output Types | Relay-compatible or transistor-compatible outputs |
| Output Voltage | 24 VDC typical (configurable per module) |
| Output Current Rating | 0.5 A per channel typical |
| Output Isolation | Channel-to-channel and channel-to-backplane isolation |
| Switching Time | <1 ms typical per channel |
| Diagnostic Features | Output status, short-circuit, and wiring fault detection via PLC |
| User Memory | Not applicable (digital output module) |
| Backplane Power Supply | +5 VDC and +12 VDC from Series 90-70 backplane |
| Power Consumption | Typical < 3 W |
| Operating Temperature | 0 °C to 60 °C (32 °F to 140 °F) |
| Storage Temperature | −40 °C to 85 °C |
| Relative Humidity | 5% to 95%, non-condensing |
| Vibration Resistance | Meets GE industrial specifications for Series 90-70 modules |
| Module Housing | Standard Series 90-70 industrial enclosure |
| Module Dimensions | Fits a single Series 90-70 PLC rack slot |
| Mounting Method | Series 90-70 PLC rack installation |
| Typical Applications | Motor control, solenoid actuation, indicator lights, industrial automation |
| Lifecycle Status | Mature product, widely deployed in industrial environments |
FAQ
Q1: How many output channels does the IC697MDL340 provide?
A1: It provides eight independent isolated digital output channels for versatile control.
Q2: What types of loads can it drive?
A2: Relay, solid-state devices, small motors, solenoids, and indicator lights.
Q3: Does the module include diagnostics?
A3: Moreover, output status and fault detection are available through PLC diagnostics.
Q4: Is this module compatible with Series 90-70 PLCs?
A4: Yes, IC697MDL340 is fully compatible with all Series 90-70 PLC systems.
Q5: Can it be used in high-speed automation processes?
A5: Therefore, it supports fast switching and precise output timing for critical applications.
