Overview
It accurately monitors high-frequency input signals, converting them into real-time digital data for PLC logic processing.
Moreover, the module supports multiple counting modes, enhancing flexibility for complex automation tasks.In addition, IC697HSC700 integrates seamlessly with standard Series 90-70 backplanes, enabling high-speed operations without additional interface hardware.
Therefore, engineers rely on this module to maintain precise event tracking and timing accuracy in demanding industrial applications.
Specification
| Category | Parameter | Specification |
|---|---|---|
| Manufacturer | Brand | GE Automation |
| Model | Product Number | IC697HSC700 |
| Module Type | Function | High-Speed Counter (HSC) Module |
| System Compatibility | Controller | Series 90-70 PLC |
| Channels | Number of Counters | 4 independent channels |
| Input Frequency | Max Counting Rate | 1 MHz per channel |
| Counting Modes | Supported Modes | Up, Down, Up/Down, Quadrature, Edge-Triggered |
| Input Signal Types | Voltage Range | 5 Vdc TTL compatible |
| Input Signal Types | Current | 10 mA maximum input per channel |
| Isolation | Channel-to-Channel | Optically isolated, 1500 V rms |
| Isolation | Channel-to-Backplane | Optically isolated, 1500 V rms |
| Resolution | Digital Conversion | 32-bit counting |
| Response Time | Typical | 1 µs per pulse |
| Power Requirements | Voltage | 5 Vdc from backplane |
| Power Requirements | Consumption | 3 W typical |
| Mechanical | Mounting | Rack-mounted, Series 90-70 backplane |
| Mechanical | Dimensions | 12.7 cm × 3.8 cm × 14.6 cm |
| Mechanical | Weight | 0.9 kg (approx. 2 lbs) |
| Environmental | Operating Temperature | 0–60 °C |
| Environmental | Storage Temperature | –40–85 °C |
| Environmental | Humidity | 5–95% non-condensing |
| Certifications | Standards | UL, CE, CSA approved |
| Reliability | MTBF | >100,000 hours at rated load |
FAQ
A1: Each channel supports high-speed counting up to 1 MHz for precise process monitoring.
Q2: How many counter channels does this module provide?
A2: It provides four independent high-speed counter channels per module.
Q3: Which counting modes are supported?
A3: Up, Down, Up/Down, Quadrature, and Edge-Triggered counting modes are available.
Q4: Is the module compatible with older Series 90-70 PLC racks?
A4: Yes, it integrates directly into standard Series 90-70 backplanes without additional hardware.
Q5: Can the module operate in harsh industrial conditions?
A5: Yes, it supports 0–60 °C operating temperature and 5–95% non-condensing humidity.
