Overview
Additionally, this module features robust electrical and mechanical construction, ensuring stable operation under demanding industrial conditions. The IC693MDL741 supports 24V DC outputs while maintaining energy efficiency and precise signal management. Its compact 30 mm width allows efficient utilization of rack space without sacrificing performance.
Specification
| Parameter | Specification |
|---|---|
| Model | IC693MDL741 |
| Manufacturer | GE |
| Series | Series 90-30 |
| Module Type | Digital Output Module |
| Output Points | 16 |
| Output Voltage | 24 V DC |
| Maximum Load Current | 0.5 A per point |
| Minimum Load Current | 10 mA per point |
| Response Time | 1 ms typical |
| Isolation | Optically isolated outputs |
| Power Dissipation | 2 W typical |
| Backplane Interface | Compatible with Series 90-30 racks |
| Status Indicators | LED per output channel |
| Module Width | 30 mm |
| Module Height | 100 mm |
| Module Depth | 90 mm |
| Weight | 0.15 kg |
| Operating Temperature | 0–60°C |
| Storage Temperature | -20–70°C |
| Humidity | 5–95% non-condensing |
| Vibration Resistance | 5–9 Hz: ±3.5 mm, 9–150 Hz: 0.75 g |
| Shock Resistance | 10 g, 11 ms half-sine pulse |
| Mounting | Rack mount in Series 90-30 chassis |
| Certifications | CE, UL listed |
| Energy Consumption | 2 W maximum |
| Typical Applications | Industrial automation, process control, high-speed digital output systems |
FAQ
Q1: Is the IC693MDL741 brand new and original?
A1: Yes, all IC693MDL741 modules are full new, factory-sealed, and manufactured by GE.
Q2: How many outputs does the module provide?
A2: The module provides 16 discrete 24V DC outputs.
Q3: What is the maximum load current per output?
A3: Each output supports up to 0.5 A at 24 V DC.
Q4: What are the module dimensions?
A4: The IC693MDL741 measures 30 mm wide, 100 mm tall, and 90 mm deep.
Q5: How long does shipping take?
A5: Delivery occurs within 3 days to 2 weeks depending on order size, using carriers like DHL, FedEx, or UPS.
Q6: Do you support returns if there is a quality issue?
A6: Yes, we provide a 30-day return policy for any quality-related issues.
Q7: Can this module operate in high-temperature environments?
A7: It supports an operating range of 0–60°C and storage from -20–70°C.
