Overview
The GE IC694CHS392 Rx3i PACSystems base expansion provides a stable and scalable foundation for distributed PLC architectures.
Moreover, this 10-slot expansion base allows engineers to increase I/O capacity without redesigning the main control rack.
Therefore, automation systems gain flexibility while maintaining consistent backplane communication and mechanical alignment.
In addition, GE designed the Rx3i base series to support long-term system expansion and lifecycle continuity.
Specification
| Parameter | Specification |
|---|---|
| Manufacturer | GE Fanuc / GE Automation |
| Model Number | IC694CHS392 |
| Series | Rx3i PACSystems |
| Module Type | Expansion Base Chassis |
| Expansion Slot Count | 10 slots |
| CPU Slot | None – expansion only |
| Supported Modules | Rx3i I/O modules, analog modules, specialty modules |
| Backplane Type | Integrated parallel backplane |
| Backplane Function | Provides power distribution and deterministic data communication |
| Expansion Interface | Connects to main Rx3i base via expansion cabling |
| Power Supply | Supplied through main Rx3i system power supply |
| Energy Storage | None (no internal batteries or capacitors) |
| Mounting Type | Panel-mounted, horizontal installation |
| Mounting Orientation | Horizontal, secured via standard industrial fasteners |
| Construction Material | Industrial-grade metal frame with reinforced backplane support |
| Slot Alignment | Precision-machined for stable module retention under vibration |
| Cooling Method | Natural convection airflow |
| Backplane Connectivity | Each slot features multi-pin edge connector for I/O modules |
| Module Compatibility | Supports all Rx3i digital, analog, and specialty modules in expansion racks |
| Approximate Width | 442 mm (17.4 inches) |
| Approximate Height | 130 mm (5.1 inches) |
| Approximate Depth | 142 mm (5.6 inches) |
| Approximate Weight | 3.6 kg (7.9 lb) |
| Operating Temperature | 0°C to 60°C (32°F to 140°F) |
| Storage Temperature | -40°C to 85°C (-40°F to 185°F) |
| Operating Humidity | 5% to 95% non-condensing |
| Environmental Rating | Industrial control cabinet environment |
| Vibration Resistance | Designed to withstand standard industrial vibration conditions |
| Shock Resistance | Fixed panel mounting ensures stability under shock conditions |
| Service Life | Long-term continuous operation in industrial automation environments |
