Overview
It delivers a reliable interface for analog input modules, enabling engineers to convert signals precisely and acquire data efficiently.
Moreover, this module actively facilitates seamless communication between analog I/O cards and the 90-70 backplane architecture.
In addition, IC697ALG230 directly supports multiple analog input channels, which allows integration into complex industrial process control applications.
Therefore, engineers choose this module because it ensures stable performance, provides accurate measurements, and enables straightforward system expansion.
Furthermore, its compact design optimizes cabinet space while maintaining robust operational reliability.
Specification
| Category | Parameter | Specification |
|---|---|---|
| Manufacturer | Brand | GE Automation |
| Model | Product Number | IC697ALG230 |
| Module Type | Function | Analog Input Base Converter |
| System Compatibility | Controller | GE Series 90-70 PLC |
| Analog Channels | Number | Supports up to 16 analog input modules |
| Conversion Type | Signal | 12- or 16-bit analog-to-digital conversion |
| Backplane Interface | Type | 90-70 Series high-speed backplane connection |
| Input Voltage | Range | ±10 VDC standard input range |
| Input Current | Maximum | 20 mA per channel |
| Accuracy | Resolution | ±0.1% full-scale accuracy |
| Power Requirements | Voltage | Supplied via 90-70 backplane |
| Power Requirements | Consumption | ≤3 W typical per module |
| Mechanical | Mounting | DIN-rail or rack mount compatible |
| Mechanical | Dimensions | 130 mm × 30 mm × 110 mm |
| Mechanical | Weight | 0.45 kg (approx. 1 lb) |
| Environmental | Operating Temperature | 0–60 °C |
| Environmental | Storage Temperature | –40–85 °C |
| Environmental | Humidity | 5–95% non-condensing |
| Certifications | Standards | UL, CE approved |
| Reliability | MTBF | >80,000 hours under rated conditions |
FAQ
A1: IC697ALG230 supports up to 16 analog input modules for high-resolution signal acquisition.
Q2: What is the input voltage range for this module?
A2: The module accepts a ±10 VDC standard input range for analog signals.
Q3: Can it integrate with Series 90-70 backplanes?
A3: Yes, it integrates seamlessly with GE Series 90-70 PLC backplane architectures.
Q4: What are the operating environmental conditions?
A4: Safe operation occurs from 0–60 °C and 5–95% non-condensing humidity.
Q5: How quickly can you ship and what is the return policy?
A5: Units are stocked, shipping occurs in 3 days–2 weeks depending on order. Returns are supported within 30 days for quality issues.
