Overview
Additionally, this module features durable electrical and mechanical construction, which ensures stable operation under demanding industrial conditions. The IC694MDL940 supports 24V DC outputs with efficient energy management and precise signal handling. Its compact 30 mm width enables optimal rack space usage without compromising functionality.
Specification
| Parameter | Specification |
|---|---|
| Model | IC694MDL940 |
| Manufacturer | GE |
| Series | Rx3i Pacsystem |
| Module Type | Discrete Output Module |
| Output Points | 16 |
| Output Voltage | 24 V DC |
| Maximum Load Current | 0.5 A per point |
| Minimum Load Current | 10 mA per point |
| Response Time | 1 ms typical |
| Isolation | Optically isolated outputs |
| Power Dissipation | 2 W typical |
| Backplane Interface | Compatible with Rx3i rack |
| Status Indicators | LED per output channel |
| Module Width | 30 mm |
| Module Height | 100 mm |
| Module Depth | 90 mm |
| Weight | 0.15 kg |
| Operating Temperature | 0–60°C |
| Storage Temperature | -20–70°C |
| Humidity | 5–95% non-condensing |
| Vibration Resistance | 5–9 Hz: ±3.5 mm, 9–150 Hz: 0.75 g |
| Shock Resistance | 10 g, 11 ms half-sine pulse |
| Mounting | Rack mount in Rx3i chassis |
| Certifications | CE, UL listed |
| Energy Consumption | 2 W maximum |
| Typical Applications | Industrial automation, process control, high-speed digital output systems |
FAQ
Q1: Is the IC694MDL940 brand new and original?
A1: Yes, all IC694MDL940 modules are full new, factory-sealed, and manufactured by GE.
Q2: How many outputs does the module provide?
A2: The module provides 16 discrete 24V DC outputs.
Q3: What is the maximum load current per output?
A3: Each output supports up to 0.5 A at 24 V DC.
Q4: What are the module dimensions?
A4: The IC694MDL940 measures 30 mm wide, 100 mm tall, and 90 mm deep.
Q5: How long does shipping take?
A5: Delivery occurs within 3 days to 2 weeks depending on order size, using carriers such as DHL, FedEx, or UPS.
Q6: Do you support returns if there is a quality issue?
A6: Yes, we provide a 30-day return policy for any quality-related issues.
Q7: Can this module operate in high-temperature environments?
A7: It supports an operating range of 0–60°C and storage from -20–70°C.
