Overview
Moreover, it prevents signal reflections and maintains reliable communication between Series 90-30 modules.
Therefore, engineers use IC693ACC307 to guarantee system stability and data integrity in PLC networks.
Specification
| Parameter | Specification | Notes / Details |
|---|---|---|
| Manufacturer | GE Fanuc | Original Series 90-30 module |
| Product Series | Series 90-30 | For PLC I/O bus expansion |
| Module Type | I/O Bus Terminator Plug | End-of-line bus termination |
| Model Number | IC693ACC307 | Exact OEM part number |
| Bus Type | Series 90-30 I/O expansion bus | Compatible with Rx3i backplane and 90-30 I/O modules |
| Termination Type | Fixed resistor network | Provides proper impedance matching to prevent signal reflection |
| Maximum Current | 50 mA | Limits for each I/O channel in the bus segment |
| Voltage Rating | 5–24 V DC | Compatible with Series 90-30 backplane voltage levels |
| Signal Integrity | Maintains proper digital signal levels | Prevents communication errors in long bus runs |
| Connector Type | 32-pin backplane connector | Direct insertion into I/O bus slot |
| Mounting | Snap-in / slot-mounted | Easy installation at the end of the I/O bus chain |
| Dimensions (W × H × D) | 20 × 120 × 100 mm | Compact form factor for space-saving installation |
| Weight | 0.1 kg | Lightweight, does not stress backplane connectors |
| Operating Temperature | 0–60 °C | Standard industrial environment |
| Storage Temperature | −40 to 85 °C | Safe for warehouse or shipping conditions |
| Vibration Resistance | 0.25 g at 5–500 Hz | Suitable for industrial environments |
| Certifications | CE, UL | Meets international safety standards |
| LED Indicators | None | Terminator plug does not include LEDs |
| Recommended Usage | End of I/O bus | Required for proper bus signal termination in all PLC systems |
| Shelf Life | Indefinite | Unused units remain functional indefinitely if stored properly |
| Maintenance | None required | Plug is passive; no servicing needed |
FAQ
Q1: Is the GE IC693ACC307 new and original?
A1: Yes, all IC693ACC307 units are brand-new, original GE factory products.
Q2: Is IC693ACC307 in stock?
A2: Yes, we maintain ready inventory of IC693ACC307 for immediate shipment.
Q3: How fast can the module be shipped?
A3: Orders typically ship within three days to two weeks depending on quantity and destination.
Q4: Which shipping carriers are commonly used?
A4: We usually ship IC693ACC307 via DHL and other reliable international carriers.
Q5: What is the primary function of IC693ACC307?
A5: IC693ACC307 ensures proper termination of Series 90-30 I/O bus systems.
Q6: What is your return policy if there are quality issues?
A6: Returns or exchanges are supported within thirty days after delivery if quality problems occur.
