Overview
Specification
| Parameter | Specification |
|---|---|
| Product Type | Power Supply Module |
| Manufacturer | HIMA |
| Model Number | F7130A |
| Input Voltage | 100–240 V AC, 50/60 Hz |
| Output Voltage | 24 V DC nominal |
| Output Current | 2.5 A continuous |
| Efficiency | >85% typical |
| Ripple & Noise | ≤50 mV pp |
| Protection | Overcurrent, short-circuit, overvoltage |
| Operating Temperature | 0°C to 60°C |
| Storage Temperature | –20°C to 70°C |
| Mounting | DIN rail or HIMatrix rack mount |
| Status Indicators | LED for power and fault conditions |
| Safety Certification | SIL 3 according to IEC 61508 / IEC 61511 |
| Dimensions (W×H×D) | Approx. 40 mm × 120 mm × 120 mm |
| Weight | ~0.4 kg |
FAQ
A1: The module provides a stable 24 V DC output.Q2: What is the maximum output current?
A2: The module delivers up to 2.5 A continuous current.
Q3: Is the module suitable for SIL 3 applications?
A3: Yes, it is certified SIL 3 according to IEC 61508 and IEC 61511 standards.
Q4: How is the module mounted?
A4: It supports DIN rail or HIMatrix rack installation for flexible deployment.
Q5: Does it include protection features?
A5: Yes, the module features overcurrent, short-circuit, and overvoltage protection.
