Overview
It provides secure electrical connections between modules, ensuring consistent data and power transfer.
Moreover, its DIN rail mounting allows flexible and compact installation in control cabinets.
Engineers prefer the H7506 for its robust design and high operational reliability under industrial conditions.
Specification
| Parameter | Specification |
|---|---|
| Model | H7506 |
| Manufacturer | HIMA |
| Product Type | DIN Mount Bus Terminal |
| Function | Bus communication and signal distribution in HIMatrix systems |
| Bus Protocol | HIBUS‑2 (RS‑485) compatible for safe system communication |
| PES Compatibility | Single‑channel PES and redundant PES modules (e.g., H41q/H51q) |
| Bus Interface Connector | 25‑pole Min‑D socket for data connection |
| Bus Wiring Terminals | Two 6‑pole plug clamps for 2‑wire bus wiring |
| Switchable Terminating Resistors | Yes — two switches activate termination at bus ends |
| Support Cable Types | Data cables BV 7040 and BV 7046 |
| Maximum Transmission Length | 1200 m @ 0.25 mm²; 2400 m @ 0.5 mm² |
| Loop Resistance | 180 ohm termination loop |
| Rated Voltage | Typically 24 V DC system level |
| Operating Temperature | –20°C to +60°C |
| Storage Temperature | –40°C to +85°C |
| Protection Class | IP20 for indoor industrial cabinet use |
| Mounting | 35 mm DIN rail per DIN 46277 standard |
| Material / Housing | Industrial metal or reinforced enclosure |
| Dimensions | 51 mm x 127 mm x 51 mm |
| Weight | ~0.5 kg |
| Indicators | Status or termination switch indicators on board |
| Reliability Features | High vibration tolerance and electrical isolation |
| Compliance / Origin | Manufactured in Germany, CE compliant |
FAQ
A1: It uses standard DIN rail mounting for flexible and compact cabinet installation.Q2: How many connections does each H7506 module provide?
A2: It provides 12 screw terminal connections for reliable bus distribution.
Q3: Can the module withstand harsh industrial conditions?
A3: Yes, it resists vibration, temperature extremes, and electromagnetic interference.
Q4: Which systems typically use the H7506 bus terminal?
A4: It is used in HIMatrix input, output, CPU, and safety controller interconnections.
