Overview
It simplifies wiring between CPUs, I/O modules, and peripheral devices in industrial automation systems.
Moreover, the board ensures signal integrity, reducing the risk of communication errors in safety-critical applications.
Engineers rely on this connector board to maintain organized, high-reliability connections across complex safety system architectures.
Specification
| Parameter | Specification |
|---|---|
| Model | F7546 |
| Alternative Name | F 7546 |
| Manufacturer | HIMA |
| Product Type | Connector Board |
| Function | Signal routing and module interconnection |
| Compatible Modules | HIMatrix CPU and I/O modules |
| Connector Type | Standard industrial connectors |
| Signal Channels | Multiple, depending on configuration |
| Supply Voltage | 24 V DC nominal |
| Operating Temperature | -20°C to +60°C |
| Storage Temperature | -40°C to +85°C |
| Housing | PCB with industrial-grade insulation |
| Protection Class | IP20 |
| Mounting Method | DIN rail or cabinet panel |
| Reliability Features | Vibration-resistant, electrical isolation |
| Maintenance | Tool-free installation and module replacement |
FAQ
A1: It provides reliable connectivity between HIMatrix CPUs, I/O modules, and peripheral devices.
Q2: Can the F7546 be installed without specialized tools?
A2: Yes, the board supports tool-free installation and quick module replacement.
Q3: What environmental conditions can this connector board withstand?
A3: It operates from -20°C to +60°C and tolerates standard industrial vibration and humidity.
Q4: Which industries commonly use the F7546 connector board?
A4: Typical applications include chemical, oil and gas, power generation, and industrial automation.
