TC-ODD321 Honeywell Experion PKS C200 32-Point Discrete Output Module

Overview

The TC-ODD321, part of Honeywell’s Experion PKS series, is a 32-point discrete output module designed for advanced process automation.
It enables reliable switching of multiple field devices and actuators, providing precise control over industrial processes.
Moreover, the TC-ODD321 supports fast response times and ensures consistent signal integrity for mission-critical applications.

Engineered for high-performance control systems, the TC-ODD321 integrates seamlessly with Experion C200 controllers.
Therefore, it is ideal for chemical, energy, and manufacturing plants requiring robust and scalable digital output solutions.

Specification

Parameter	Specification
Number of Outputs	32(16 pointsloommon)
Output Voltage Range	10-31.2 VDC @50℃(Linear derating) 10-28  VDC@60°
Output Current Rating Per PointPer Module	0.5A maximum @50℃(Linear derating) 0.35A     maximum@60C 16A maximum@50°℃(Linear derating) 10A    maximum@60℃
Surge Current	1A for 10ms each,repeatable every 2s@60C
Flash On Time	100 μsec target,150 μsec max
On-State Current Load(Minimum)	3.0 mA per output
On-State Voltage Drop(Maximum)	1 VDC@rated current per point (3VDC for IEC 1131-2)
Off-State Leakage Current (Maximum)	0.5mA per point (1mA per point IEC 1131-2 for 0.25 A output)
Configurable Fault States per Point	Hold Last State,ON or OFF(OFF is the default)
Configurable States in Program Mode per Point	Hold Last State,ONor OFF(OFF is the defauilt)
Fusing	Not protected-Fused IFM is reoommended to protect outputs
Reverse Polarity Protection	None-If module is wired incorreclly,outputs may be damaged
Output Delay Time Offto on On to off	1.0 ms maximum 1.0 ms maximum
Power Dissipation	6.1W
Backplane Current	See Module Power Consumption Data,page 46.
lsolation Voltage Group to group User to system	100%tested at 2546V dc for 1s (250V ac maximum continuous voltage between groups) 100%tested at 2546V dc for 1s
Connection Terminal Blocks	TC-TBCH,36-posilion terminal block

FAQ

Q1: What is the main purpose of the Honeywell TC-ODD321?
The TC-ODD321 provides 32 discrete output points for controlling field devices in Experion PKS systems.

Q2: Is the TC-ODD321 an original Honeywell product?
Yes, all TC-ODD321 units we supply are brand-new, original Honeywell products.

Q3: Is the TC-ODD321 in stock and how fast can it ship?
We keep TC-ODD321 units in stock and ship within three days to two weeks depending on order size.

Q4: Which logistics services are used for TC-ODD321 shipments?
We typically ship TC-ODD321 using DHL or other reliable express carriers.

Q5: What warranty or return policy applies to the TC-ODD321?
We support 30-day returns for the TC-ODD321 if verified quality issues occur after delivery.
