Overview
The ABB NKLS01-10, also cataloged as the NKLS01-10 INFI-Net Interface Cable, operates as a dedicated hardware component for connecting an NIS interface to an NTCL connection point within ABB INFI-Net system installations. The prefabricated PVC cable provides a defined physical interconnection and is supplied in a 10 ft configuration.
Hardware Specifications
| Parameter | Specification |
|---|---|
| Model | NKLS01-10 |
| Brand | ABB |
| Product Type | Prefabricated Cable |
| Catalog Description | INFI-Net Interface Cable – 10 Ft (PVC) |
| Primary Function | Connect NIS to NTCL |
| Cable Length | 10 ft |
| Cable Material | PVC |
| Product Net Depth / Length | 63.5 mm |
| Product Net Height | 292.1 mm |
| Product Net Width | 292.1 mm |
| Dimensions | 63.5 mm x 292.1 mm x 292.1 mm |
| Weight | 0 kg specified |
| Cable Diameter | 0.0635 mm specified |
| Operating Temp | Not specified in provided data |
| Power Consumption | Passive cable; no independent power consumption specified |
| HS Code | 854442 |
| Customs Tariff Number | 85444290 |
| WEEE Category | Product Not in WEEE Scope |
| Connection Function | NIS to NTCL |
ABB Industrial Network Interface Characteristics
The NKLS01-10 functions as a prefabricated physical connection component rather than an active I/O or communication processor. Therefore, it does not provide independent backplane bus communication processing, firmware execution, or configurable I/O density.
Instead, the cable supports the required physical connection path between the NIS and NTCL hardware interfaces. Correct cable routing and connector engagement help maintain the intended communication path within ABB INFI-Net installations. In addition, installation practices should prevent excessive mechanical stress, sharp bends, and unintended separation from connected equipment.
Frequently Asked Questions
Q: Does the ABB NKLS01-10 require an external power supply?
A: No independent power consumption is specified because the NKLS01-10 is identified as a prefabricated interface cable.
Q: What equipment does the NKLS01-10 connect?
A: The provided ABB product information specifies that the cable connects NIS to NTCL.
Q: Does the NKLS01-10 require firmware configuration?
A: No firmware function or upgrade requirement is specified for this prefabricated cable. Configuration requirements apply to the connected active system hardware where applicable.
Field Installation Guidelines
- Verify that the cable model is NKLS01-10 before installation.
- Confirm that the installation requires the specified connection between NIS and NTCL equipment.
- Route the cable away from sharp edges and locations that can cause insulation damage.
- Avoid excessive pulling force, crushing, twisting, or bending beyond the cable manufacturer’s permitted limits.
- Ensure connectors are fully engaged before energizing or commissioning the associated system.
- Keep cable routing organized and separated from sources of excessive electrical interference where practical.
- Inspect the cable jacket and connector interfaces for physical damage before installation.
- Do not modify the prefabricated cable assembly unless the applicable ABB system documentation explicitly permits modification.
