Overview
The ABB 3BSE018151R1, also cataloged as the PM864 Processor Module, operates as a dedicated hardware component for control logic execution, application processing, and controller communication within the ABB System 800xA AC800M platform.
Hardware Specifications
| Parameter | Specification |
|---|---|
| Model | PM864 |
| Brand | ABB |
| Product Type | Processor Module |
| Series | System 800xA AC800M |
| Article Number | 3BSE018151R1 |
| Origin | China |
| Weight | 0.5 kg (1 lbs 2.1 oz) |
| Dimensions | 12.7 cm x 12.7 cm x 12.7 cm |
| Operating Temp | Not specified |
| Power Consumption | Not specified |
| System Platform | ABB System 800xA AC800M |
| Function | CPU processing and controller application execution |
| Installation Type | AC800M controller hardware assembly |
| Tariff Code | 8537109060 |
Firmware and Industrial Control Platform Compatibility
The ABB PM864 Processor Module provides execution resources for AC800M controller applications, including cyclic control tasks, communication handling, and process data management through the System 800xA automation environment. The module operates as part of the AC800M controller architecture with backplane communication between controller hardware components.
The AC800M platform supports industrial control configurations requiring deterministic controller task execution, I/O density scaling, and firmware flash compatibility management for controller lifecycle maintenance. The PM864 hardware is configured for integration with ABB controller assemblies using the specified processor module interface.
Frequently Asked Questions
Q: What is the primary function of the ABB PM864 module?
A: The PM864 is a processor module for ABB System 800xA AC800M controllers. It executes controller application logic and manages communication between controller hardware components.
Q: Is the PM864 a standalone controller or an expansion I/O module?
A: The PM864 is a CPU processor module. It is installed as part of an AC800M controller configuration and is not an independent I/O expansion module.
Q: Can the PM864 be installed in any AC800M configuration?
A: Installation compatibility depends on the specific AC800M controller hardware configuration, firmware version, and engineering system requirements.
Field Installation Guidelines
- Install the PM864 Processor Module only in the designated ABB AC800M controller hardware assembly.
- Verify mechanical alignment before inserting the module into the controller backplane connection.
- Use appropriate ESD protection procedures when handling the processor module.
- Maintain proper grounding and shielding practices for connected communication and I/O wiring.
- Route signal and power cables separately where required by industrial control cabinet installation standards.
- Confirm firmware compatibility and controller configuration parameters before commissioning.
