Overview
Configured for serial communication within an ABB control system, the ABB CI853K01 3BSE018103R1 (CI853K01 Communication Interface) provides a dual RS232-C interface. The package includes the CI853 communication interface and TP853 baseplate. It operates from 24 VDC power and supports electrical isolation up to 500 V AC between the specified input and power circuits.
Hardware Specifications
| Parameter | Specification |
|---|---|
| Model | CI853K01 3BSE018103R1 |
| Spare Model | 3BSE018103R1 |
| Brand | ABB |
| Product Type | Communication Interface |
| Interface | Dual RS232-C Interface |
| Communication Port | 1 x Ethernet, RJ45 |
| Baseplate | TP853 |
| Power Supply | 24 VDC, +/- 20% |
| Power Consumption | 6 W maximum |
| Isolation Voltage | 500 V AC, input/power |
| Origin | Sweden |
| Weight | 0.44 kg |
| Dimensions | Estimated shipping size: 18.7 x 6.7 x 12.7 cm |
| Operating Temp | -20 deg C to +60 deg C |
| Storage Temp | -40 deg C to +85 deg C |
| Humidity | 5-95% RH, non-condensing |
| Vibration | 5-150 Hz, 1 G, IEC 60068-2-6 |
| Tariff Code | 8537101190 |
| Manufacturer | ABB |
| Shipment Origin | Xiamen, China |
Serial Interface and Backplane Considerations
The CI853K01 provides a dual RS232-C interface for serial communication. Therefore, installation should maintain appropriate separation between communication wiring and high-current or high-noise conductors. The supplied specifications also identify an Ethernet RJ45 port, so technicians should verify the intended communication path against the system hardware configuration before commissioning.
The TP853 baseplate provides the physical mounting interface for the CI853 communication interface. In addition, the module requires a 24 VDC supply within the specified +/- 20% range. The stated 6 W maximum power consumption should be considered when sizing the associated power supply.
The supplied data does not specify backplane communication speed, supported Ethernet protocols, cable lengths, or firmware compatibility. Therefore, these parameters require confirmation from the applicable ABB system documentation before integration.
Frequently Asked Questions (FAQ)
Q: What communication interface does the CI853K01 provide?
A: The supplied product data identifies a dual RS232-C interface and one Ethernet RJ45 communication port.
Q: What power supply does the CI853K01 require?
A: The module operates from a 24 VDC supply with a specified tolerance of +/- 20%. Maximum power consumption is 6 W.
Q: What environmental conditions apply during operation?
A: The specified operating range is -20 deg C to +60 deg C with 5-95% RH non-condensing humidity. Vibration resistance is specified as 5-150 Hz at 1 G according to IEC 60068-2-6.
Field Installation Guidelines
- Install the CI853K01 on the specified TP853 baseplate and secure the assembly according to the applicable ABB installation procedure.
- Verify the 24 VDC supply polarity and voltage before energizing the module.
- Route RS232-C communication cables separately from high-voltage, motor, and high-current power wiring where practical.
- Maintain cable shielding and grounding practices consistent with the control system grounding design.
- Protect the RJ45 Ethernet connection from mechanical strain and excessive cable bending.
- Confirm connector seating before applying power or starting communication diagnostics.
- Keep the module within the specified -20 deg C to +60 deg C operating temperature range.
- Avoid condensation and maintain the specified 5-95% RH non-condensing environment.
- Verify the installation location does not exceed the specified vibration condition of 5-150 Hz at 1 G.
- Confirm the applicable ABB controller, firmware, communication protocol, and baseplate compatibility before commissioning.
