Overview
Specifically, it serves the GE RX7i PACSystems platform in demanding industrial environments.
Engineers rely on this module to maintain consistent backplane power across complex PLC configurations.
Moreover, it supports high-density racks where dependable current delivery remains essential.Under fluctuating plant conditions, the unit actively stabilizes voltage and manages heavy I/O loads.
As a result, automation systems maintain predictable performance during continuous industrial operation.
In addition, its rugged construction withstands vibration, electrical noise, and temperature variations.
Therefore, manufacturing, energy, and infrastructure facilities achieve long-term operational reliability.
Specification
| Parameter | Specification |
|---|---|
| Manufacturer | GE Intelligent Platforms |
| Model Number | IC698PSD300 |
| Product Type | Power Supply Module |
| Series | GE RX7i PACSystems |
| Rated Input Voltage | 24 VDC nominal |
| Input Voltage Range | 18 to 30 VDC |
| Maximum Output Power | 300 Watts |
| Backplane Output Voltage | 5 VDC regulated (primary logic supply) |
| 5 VDC Output Current | Up to 60 A (system dependent) |
| Efficiency | High-efficiency switching design |
| Inrush Current | Controlled soft-start design |
| Protection Features | Overcurrent, short circuit, overvoltage, thermal shutdown |
| Isolation | Input to backplane isolation |
| Power Derating | Required above 50°C depending on airflow |
| Operating Temperature Range | 0°C to 60°C (32°F to 140°F) |
| Storage Temperature Range | -40°C to 85°C (-40°F to 185°F) |
| Relative Humidity | 5% to 95% non-condensing |
| Cooling Method | Natural convection or forced air within enclosure |
| Mounting | Direct installation into RX7i rack |
| Diagnostics | Front-panel LED status indicators |
| Redundancy Support | Compatible with redundant power configurations (system dependent) |
| Compliance | CE, UL, CSA, industrial EMC standards |
| Application Environment | Industrial control panels and automation cabinets |
| Expected Service Life | Designed for continuous industrial operation |
FAQ
Q1: What systems is the IC698PSD300 designed for?
It is specifically designed for the GE RX7i PACSystems platform.
Q2: What is the maximum output power capacity?
The module delivers up to 300 watts of regulated output power.
Q3: What input voltage does this power supply require?
It operates on a nominal 24 VDC input with an 18–30 VDC range.
Q4: Does the module include protection features?
Yes, it includes overcurrent, overvoltage, and thermal protection mechanisms.
Q5: Is it suitable for high-density PLC racks?
Yes, it supports multiple CPUs and I/O modules within large RX7i configurations.
