Overview
Specifically, it establishes seamless communication between the GE RX3i PACSystems platform and PROFIBUS DP master systems.
Engineers select this module when they require reliable fieldbus integration in distributed automation environments.
Moreover, it delivers deterministic cyclic data exchange for time-critical industrial applications.
The module installs directly into the RX3i universal backplane without additional adapters.
As a result, system designers extend network connectivity without redesigning the PLC architecture.
In addition, its rugged construction withstands electrical noise and vibration in demanding plants.
Therefore, manufacturing and process control facilities maintain stable and predictable fieldbus performance.
Specification
| Parameter | Specification |
|---|---|
| Manufacturer | GE Intelligent Platforms |
| Model Number | IC695PBS301 |
| Series | GE RX3i PACSystems |
| Module Type | PROFIBUS DP Slave Module |
| Communication Protocol | PROFIBUS DP, supports DP-V1 Read/Write and alarms |
| Data Capacity | Up to 244 bytes input / 244 bytes output |
| Supported Data Rates | 9.6 Kbps to 12 Mbps selectable |
| Connector Type | 9-pin D-sub PROFIBUS interface |
| Backplane Compatibility | RX3i PCI universal backplane |
| Slot Requirement | Single slot installation |
| Backplane Current Draw | Approx. 440 mA @ 3.3 VDC |
| Isolation | Network to backplane isolation |
| Diagnostics | LED indicators for module and network status |
| Operating Temperature | 0°C to 60°C |
| Storage Temperature | -40°C to 85°C |
| Humidity | 5–95% non-condensing |
| Compliance | CE, UL, CSA industrial standards |
| Application Environment | Industrial automation and distributed control systems |
FAQ
Q1: What is the primary role of the IC695PBS301 module?
It enables an RX3i controller to function as a PROFIBUS DP slave device.
Q2: How much I/O data can this module manage?
It supports up to 244 bytes of input data and 244 bytes of output data.
Q3: Which communication speeds are supported?
The module supports standard PROFIBUS rates from 9.6 Kbps up to 12 Mbps.
Q4: How is the module installed?
It installs in a single slot within the RX3i universal backplane.
Q5: Does it provide diagnostic indicators?
Yes, integrated LEDs display network and module operating status.
