Overview
It supports multiple analog input types, allowing engineers to standardize diverse instrumentation on one platform.
Moreover, this module integrates seamlessly into high-performance Rx3i control systems for scalable automation projects.
Designed for demanding industrial environments, it delivers precise measurement and reliable long-term stability.
Therefore, process industries benefit from improved data accuracy and simplified wiring requirements.
Its universal design reduces spare part inventory while increasing engineering efficiency.
Specification
| Category | Parameter | Specification |
|---|---|---|
| General Information | Model Number | IC695ALG626 |
| Product Type | Universal Analog Input Module | |
| Platform | GE Rx3i PACSystems | |
| Slot Requirement | Single-slot module | |
| Backplane Interface | Rx3i high-speed PCI backplane | |
| Input Channels | Number of Channels | 8 analog input channels |
| Input Types Supported | Voltage and current inputs | |
| Voltage Input Ranges | 0–10 V DC, ±10 V DC | |
| Current Input Ranges | 0–20 mA, 4–20 mA | |
| Input Configuration | Individually configurable per channel | |
| Input Impedance | > 10 kΩ for current, > 100 kΩ for voltage | |
| HART Support | Yes, integrated HART pass-through | |
| Conversion & Performance | Resolution | 16-bit analog-to-digital conversion |
| Accuracy | ±0.1% of Full Scale Typical | |
| Total Update Time | High-speed scanning across channels | |
| Filtering | Software-configurable digital filtering | |
| Noise Immunity | Built-in filtering and isolation for noise reduction | |
| Electrical Characteristics | Backplane Power | 5 V DC and 3.3 V DC from Rx3i backplane |
| Power Consumption | Typically 1.5–2.0 W | |
| Channel Isolation | Channel-to-channel and channel-to-backplane isolation | |
| Protection Features | Overvoltage protection, HART-compatible signal path | |
| Indicators & Diagnostics | Status LEDs | Per-channel status and module health indicators |
| Fault Reporting | Diagnostic support via PLC and system tools | |
| HART Diagnostics | Indicator for active HART communication | |
| Environmental Specifications | Operating Temperature | 0°C to 60°C (32°F to 140°F) |
| Storage Temperature | –40°C to 85°C (–40°F to 185°F) | |
| Relative Humidity | 5–95% non-condensing | |
| Vibration & Shock | Designed for industrial control panel environments | |
| Mechanical Characteristics | Mounting | Rx3i rack-mounted module |
| Module Width | Standard Rx3i module width | |
| Connectors | Terminal block for analog field wiring | |
| Compliance & Standards | Certifications | CE and UL designed (system dependent) |
| Application Environment | Industrial process control and automation |
FAQ
A1: It provides eight configurable universal analog input channels.
Q2: Does the module support both voltage and current signals?
A2: Yes, each channel supports configurable voltage and current input ranges.
Q3: Is HART communication supported?
A3: Yes, the module supports integrated HART pass-through for compatible field devices.
Q4: Can the module be replaced without shutting down the system?
A4: In compatible Rx3i systems, it supports hot insertion for maintenance flexibility.
Q5: What industries typically use this module?
A5: Process control, power generation, water treatment, and OEM automation commonly use it.
