Overview
It converts external AC input power into regulated DC outputs for controllers and I/O modules.
Moreover, its robust design supports continuous operation in demanding industrial environments.
Engineers rely on this power supply when system stability and predictable performance remain critical.
Therefore, it forms a reliable foundation for medium to large-scale Rx3i automation architectures.
Its compact rack-mounted format simplifies cabinet layout and installation planning.
Specification
| Category | Parameter | Specification |
|---|---|---|
| General Information | Model Number | IC694PWR330 |
| Product Type | Power Supply Module | |
| Platform Compatibility | GE Rx3i PACSystems and compatible Series 90-30 racks | |
| Slot Requirement | Dedicated power supply slot | |
| Mounting | Rack-mounted, baseplate installation | |
| Input Power | Nominal Input Voltage | 120/240 V AC |
| Input Voltage Range | 85–264 V AC | |
| Input Frequency | 47–63 Hz | |
| Input Phase | Single-phase AC | |
| Inrush Current | Controlled internal limiting | |
| Input Protection | Internal overvoltage and surge protection | |
| Output Power | Primary Output Voltage | Regulated 5 V DC |
| Maximum 5 V DC Output Current | Up to 30 W equivalent load capacity | |
| Secondary Output Voltage | 24 V DC (system dependent) | |
| Output Regulation | Regulated DC outputs for stable PLC operation | |
| Hold-up Time | Sufficient for brief AC disturbances | |
| Protection & Safety | Overcurrent Protection | Integrated electronic limiters |
| Short-Circuit Protection | Automatic shutdown with recovery | |
| Thermal Protection | Internal thermal limiters | |
| Isolation | Input-to-output electrical isolation | |
| Electrical Characteristics | Efficiency | High-efficiency industrial performance |
| Power Dissipation | Dependent on load and environment | |
| Indicators & Diagnostics | Status LEDs | Power OK, Fault, and Output indicators |
| Diagnostic Feedback | Immediate visual status on module | |
| Environmental Specifications | Operating Temperature | 0°C to 60°C (32°F to 140°F) |
| Storage Temperature | –40°C to 85°C | |
| Relative Humidity | 5–95% non-condensing | |
| Vibration Rating | Designed for industrial control environments | |
| Mechanical Characteristics | Form Factor | Standard Rx3i / Series 90-30 compatible width |
| Cooling Method | Natural convection | |
| Housing | Rugged industrial enclosure | |
| Compliance & Standards | Designed For | Industrial automation power systems |
| Regulatory Compliance | CE and UL compatible (system dependent) |
FAQ
A1: It supports GE Rx3i PACSystems and compatible 90-30 rack configurations.
Q2: What input voltage does this power supply accept?
A2: It accepts 120/240V AC nominal input within an 85–264V AC range.
Q3: What output voltage does the module provide?
A3: It provides regulated 5V DC output and additional system-specific outputs.
Q4: Does the module include protection features?
A4: Yes, it includes overcurrent and short-circuit protection mechanisms.
Q5: Can this power supply operate in industrial environments?
A5: Yes, it operates reliably between 0°C and 60°C in control panel installations.
